Stainless Steel Tube Punching Machine
US$ 7,050 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Power Source:
Mechanical
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Machine for Punching and Forming,hot Sale Punch MachineUS$ 7,050 - 10,000MOQ: 1 Set -
Mechanical Punch Machine, Punch Press Machine for Aluminum SheetUS$ 7,050 - 10,000MOQ: 1 Set
-
Press Machine for Sheet Metal Blanking and Forming,punch Machine for SaleUS$ 7,050 - 10,000MOQ: 1 Set
-
Eccentric Press,hand Mechanical Press MachineUS$ 7,050 - 10,000MOQ: 1 Set
-
China Electric Punch Press Machine/Fixed Table Power Press 125tonUS$ 7,050 - 10,000MOQ: 1 Set
Condition
New
CNC or Not
CNC
Power Source
Mechanical
Place of Origin
Anhui, China
Brand Name
Hellen
Model Number
J23-40T
Voltage
220V/380V(According, 380 V or by customer's demand
Power(W)
11kw
Weight
1-6T
Dimension(L*W*H)
1160.900.2250
Certification
CE ISO
Warranty
2 Years
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
punch machine
Mechanical characteristics:
- Fram : The frame is of all steel construction, fabricated from Rolled steel plates with suitable cross ribbings. Presses up to 30T will be supplied with C.I. legs. proper alignment of the frame is ensured by machining.
- Clutch : The clutchis of pin/rolling key-type. the clutch is rigid and well supported. the clutch gives continuous strokes for mass production
- Crank Shaft : Crank shaft is made of special alloy steel machined to close accuracy and fitted in bronze bushes for smooth working, longer life & accuracy
- Flywheel : Properly sized flywheel, is made of high grade cast iron, for storing and releasing adequate energy for the pressing operations, and properly balanced for smooth running
- Gears : Gear are of steel cast or fabricated. Gear teeth are generated by precision hobbing machine
- Table & Ram : Table and fam are made pf high grade heavy duty cast iron & properly seasoned. They are perfectly aligned, to each other to obtain high accuracy & precision press operation
- Lubrication : An efficient shot luvrication system has been provided for lubricating the sliding surfaces and moving parts. The lubricant is applied by hand pump
- Inclining : Inclinable type presses are provided with inclining mechanism which can be easily det and locked in
- Mechanism : Position by spanners within minutes. the press ils so designed that even in maximum inclined position, it is stable under heavy pressing load
Application:
- Pressing and withdrawing axle and sleeve
- Bending and deep drawing sheet metal
- Straightening, forming, cutting and punching various materials
- Applied in compression trial.
- External cover of computer and sheet metal parts
- OA steel furniture drawer and rail parts
- External cover of air conditioner ,and sth.liked.
| Model | J21S-6.3 | J21S-10 | J21S-16 | J21S-25A | J21S-40A | J21S-63A | J21S-80A | JD21S-100A | JD21S-125A | ||
| Nominal force | KN | 63 | 100 | 160 | 250 | 400 | 630 | 800 | 1000 | 1250 | |
| Stroke under nominal force | mm | 2 | 2 | 2 | 2.5 | 4 | 4 | 5 | 6 | 6 | |
| Slide block stroke | Mm | 35 | 60 | 70 | 80 | 120 | 120 | 130 | 140 | 140 | |
| Number of stroke | Min-1 | 170 | 145 | 125 | 60 | 55 | 50 | 45 | 38 | 38 | |
| Max die set height | Mm | 110 | 130 | 170 | 180 | 220 | 270 | 290 | 320 | 320 | |
| Die set height adjusdment | mm | 30 | 35 | 45 | 70 | 80 | 80 | 100 | 100 | 100 | |
| Distance from slide block centre to the frame | mm | 400 | 400 | 400 | 400 | 400 | 450 | 450 | 450 | 450 | |
| 700 | 700 | 700 | 700 | 710 | 800 | 800 | 760 | 760 | |||
| Worktable dimensions(f.b*l.r) | mm | 200 | 240 | 320 | 400 | 480 | 480 | 4580 | 710 | 720 | |
| 310 | 360 | 480 | 600 | 710 | 710 | 610 | 1100 | 1200 | |||
| Dimensions of worktable hole (diameter*f*b*l*r) | mm | Φ60 | Φ120 | Φ100 | Φ120 | Φ220 | Φ200 | Φ200 | Φ260 | Φ260 | |
| 120 | 45 | 45 | 45 | 50 | 50 | ||||||
| Φ100 | Φ180 | Φ180 | Φ180 | Φ220 | Φ220 | ||||||
| Thickness of bolster | mm | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 120 | 120 | |
| Holedimensions in bed (diameter*f*b*l*r) | mm | Φ140 | Φ130 | Φ210 | 200 | 200 | 200 | 220 | 260 | 260 | |
| 110 | 90 | 160 | 200 | 240 | 250 | 260 | 290 | 290 | |||
| 160 | 180 | 240 | |||||||||
| Dimensions of side block bottom surface(f*b*l*r) | mm | 120 | 150 | 180 | 210 | 270 | 280 | 280 | 420 | 420 | |
| 140 | 170 | 200 | 250 | 320 | 320 | 380 | 560 | 560 | |||
| Size of the handle hole (diameter *depth) | mm | Φ30 | Φ30 | Φ40 | Φ40 | Φ50 | Φ50 | Φ60 | 60 | Φ60 | |
| 55 | 55 | 60 | 70 | 70 | 80 | 75 | 80 | 80 | |||
| Distance between columns of body | mm | 162 | 182 | 220 | 350 | 390 | 450 | 450 | 580 | 580 | |
| Motor | Type | Y2-90S-6 | Y2-90L-6 | Y2-100L-6 | Y2-100L1-4 | Y2-132M1-6 | Y2-132M1-6 | Y2-160M-2 | Y2-160M-6 | Y2-160L-6 | |
| power | Kw | 0.75 | 1.1 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 7.5 | 11 | |
| Outline dimension(f*b*l*r*h) | mm | 1540 | 1620 | 1680 | 1790 | 1965 | 2220 | 2220 | 2530 | 2550 | |
| 700 | 730 | 840 | 990 | 1180 | 1350 | 1380 | 1555 | 1610 | |||
| 1520 | 1800 | 1880 | 2288 | 2295 | 2600 | 2650 | 2990 | 2990 | |||
| Net/gross weight | kg | 820 | 1060 | 1940 | 2860 | 4400 | 5500 | 6020 | 12500 | 13500 | |
| 920 | 1160 | 2185 | 3360 | 5100 | 6300 | 6820 | 13800 | 14800 | |||
Packaging & Shipping
1 PVC film covered punching machine
2.Whole machine fixed in the container with steel rope,very safe
3.Wooden case or pallet or iron box
4.If have stock,can provide right now
5.If no stock,small machine delivery time 7-15days.Big machine delivery time 25-40days.
6.Can give destination port best price or cost to the customer factory.
Our Services
1.All machines have been tested by 48 hours before ship out.
2.All products have 2 year warranty.
3.Supported 24 hours online service. If any problems happen, our team will do our best to solve the problems.
4.If any component is damaged during guarantee time. we can send the component to the customer by DHL freely.
