Specifications
laminated tinplate1)Standard: BS, DIN, GB, JIS
2)Grade: SPHC SPCC MR
3)Temper: T1, T2, T3,T4,T5,T6,DR7,DR8
prime laminated tinplate coil for can making
Tinplate Coils is for making all types of containers such as food cans, beverage cans, and artistic cans, tea cans, painting cans, chemical package cans and dry food package cans, metal printing etc
see more tinplate coil
Infomation of laminated tinplate
| NO. | More Detail | |
| 1 | Standard | GB2520-2000, JIS G3303-2002 and DIN EN10202-2001 |
| 2 | Material | SPCC,SPHC,SPHE,MR |
| 3 | Thickness | available:0.15mm--0.5mm |
| 4 | Width | available:7120--1200mm |
| 5 | Temper grade | T1-T5,DR8-DR10,BAandCAboth. |
| 6 | Tin coating | ordinary 2.8g/2.8g, 5.6g/5.6g, We also can produce according to customers' requests |
| 7 | Coil diameter | ID 420/ 508mm, OD from 1,000 to 1,250mm |
| 8 | Package |
Thin plastic film, rust-proof paper, metal cover, metal corner, metal band, wooden skid. by sheet or coils according customer's require. |
| 9 | Applications |
metal package usage like paint, chemical can,aerosol can and different food can production, Also battery,electric cable and other industries |
The Coating Weight:
| Type | Designation of tin coating weight | Min.average tin coating weight(g/m2) | Former Coating Designation |
| Equal tin coating | 1.4/1.4 | 1.2/1.2 | #15 |
| 2.2/2.2 | 2.0/2.0 | #20 | |
| 2.8/2.8 | 2.45/2.45 | #25 | |
| 5.6/5.6 | 5.05/5.05 | #50 | |
| 8.4/8.4 | 7.55/7.55 | #75 | |
| 11.2/11.2 | 10.1/10.1 | #100 | |
| Differentially Coating | 1.4/2.8 | 1.2/2.45 | #15/25 |
| 2.2/2.8 | 2.2/2.45 | #20/25 | |
| 2.8/5.6 | 2.45/5.05 | #25/50 | |
| 2.8/8.4 | 2.45/7.55 | #25/75 | |
| 2.8/11.2 | 2.45/10.1 | #25/100 | |
| 5.6/8.4 | 5.05/7.55 | #50/75 | |
| 5.6/11.2 | 5.05/10.1 | #50/100 | |
| 8.4/11.2 | 7.55/10.1 | #75/100 |
Surface Finish
Code |
Classification |
Specific Finishes |
B |
Bright Finish |
A luster surface provided by a flow-brightened tin coating on a smoothly grindstone finished steel base. |
R |
Stone Finish |
A luster surface provided by a flow-brightened tin coating on a steel base characterized by a directional grindstone pattern. |
S |
Silver Finish |
A luster surface provided by a flow-brightened tin coating on a coarse dull finish steel base. |
M |
Matte Finish |
A dull surface provided by an unmelted coating generally on dull finished steel base. |
Temper of Tinplate coils
Code |
Chinese Stardard |
Japaness Standard |
American Standard |
European Standard |
International Standard |
|
GB/T 2520-2000 |
JIS G3303-2002 |
ASTM A623M-2002 |
DIN EN 10203-1991 |
ISO 11949-1995 |
T-2 |
TH52+SE |
T-2 |
T-2(53) |
T52 |
TH52+SE |
T-2.5 |
TH55+SE |
T-2.5 |
|
|
TH55+SE |
T-3 |
TH57+SE |
T-3 |
T-3(T57) |
T57 |
TH57+SE |
|
|
|
|
|
|
T-4 |
TH61+SE |
T-4 |
T-4(T61) |
T61 |
TH61+SE |
The packaging of laminated tinplate
Kunry provide superior service to glabal customers,aim at becoming world-facmous company in tinplate coils industry.
The Laboratory of Kunry laminated tinplate Show :
The reason for choose Kunry laminated tinplate
The Application of laminated tinplate :
If you want parches laminated tinplate coils from kunry please contact with me immediately !
