Matte Finish Strip 0.25mm Tinplate coil for Electronic part
Details Of First ClassTinplate:
FirstclassTinplate(ETP) is a thin cold Rolled carbon steel sheet coated with Tin. Its corrosion resistance, light weight and malleability make it ideal for many precision end uses: Packaging of food and Liquids Decorative Tins Automotive Filters Office Products
Tinplate infomation:
1. Reference standard: GB2520-2000, JIS G3303-2002 and DIN EN10202-2001
2.Material:MR,SPCC,SPTE
3.Thickness:available:0.15mm--0.50mm
4.Width:available:600mm--1200mm
5.Temper grade:T1,T2,T3,T4,T5,T6,DR7,DR8,BAandCAboth.
6. Tin coating: ordinary 1.1/1.1;1.1/2.8;2.8/2.8;2.8/5.6;5.6/5.6kgs/m2, We also can produce according to customers' requests
7. Coil diameter: ID 420/ 508mm, OD from 1,000 to 1,250mm
8. Package: Seaworthy Standard with wooden pallet
9. Applications: metal package usage like paint, chemical can,aerosol can and different food can production,Also battery,electric cable and other industries
10. The price: US $ 650 - 1,200 / Metric Ton
The Tin Coating Weight:
| Type | Designation of tin coating weight | Min.average tin coating weight(g/m2) | Former Coating Designation |
| Equal tin coating | 1.4/1.4 | 1.2/1.2 | #15 |
| 2.2/2.2 | 2.0/2.0 | #20 | |
| 2.8/2.8 | 2.45/2.45 | #25 | |
| 5.6/5.6 | 5.05/5.05 | #50 | |
| 8.4/8.4 | 7.55/7.55 | #75 | |
| 11.2/11.2 | 10.1/10.1 | #100 | |
| Differentially Coating | 1.4/2.8 | 1.2/2.45 | #15/25 |
| 2.2/2.8 | 2.2/2.45 | #20/25 | |
| 2.8/5.6 | 2.45/5.05 | #25/50 | |
| 2.8/8.4 | 2.45/7.55 | #25/75 | |
| 2.8/11.2 | 2.45/10.1 | #25/100 | |
| 5.6/8.4 | 5.05/7.55 | #50/75 | |
| 5.6/11.2 | 5.05/10.1 | #50/100 | |
| 8.4/11.2 | 7.55/10.1 | #75/100 |
Features of tinplate :
1. Excellent paint adhesion can be used to produce DRD cans and plastic contact tank
2. Excellent heat denaturation temperature baking does not change color
3. Excellent resistance to sulfur
4. Excellent corrosion resistance
5. Alkali resistance excellent more suitable for basic content packaging
Steel Types
| Type | Description |
| MR |
Base steel low in residual elements that has excellent corrosion resistance. It widely used in general applications. |
| L |
Base steel extremely low in residual elements such as Cu, Ni, Co, and Mo that has excellent corrosion resistance to certain types of food Products. |
| D |
Aluminum-killed base steel used in applications involving deep drawing or other types of severe forming that tend to give rise to Lueder's lines. |
Our Services
We can provide superior service to global customers
aim at becoming world-famous company in the industry
Tianjin Kunry Steel Co.,Ltd is the largest manufacturer and exporter of tin mill products in china with advanced technical equipments
Certificate
Sales Market
If you have interest in tinplate from kunry please contact with me immediately !
