Golden Lacquering printed Tinplate sheet for metal packaging
It is for making all types of containers such as food cans, beverage cans, and artistic cans, tea cans, painting cans, chemical package cans and dry food package cans, metal printing etc
The Detail of Printed Tinplate sheet:
| NO. | More Detail | |
| 1 | Standard | GB2520-2000, JIS G3303-2002 and DIN EN10202-2001 |
| 2 | Material | SPCC,SPHC,SPHE,MR |
| 3 | Thickness | available:0.15mm--0.5mm |
| 4 | Width | available:600--1200mm |
| 5 | Temper grade | T1-T5,DR8-DR10,BAandCAboth. |
| 6 | Tin coating | ordinary 1.1/1.1;2.8g/2.8g, 5.6g/5.6g, We also can produce according to customers' requests |
| 7 | Coil diameter | ID 420/ 508mm, OD from 1,000 to 1,250mm |
| 8 | Package |
Thin plastic film, rust-proof paper, metal cover, metal corner, metal band, wooden skid. by sheet or coils according customer's require. |
| 9 | Applications |
metal package usage like paint, chemical can,aerosol can and different food can production, Also battery,electric cable and other industries |
The Coating Weight:
| Type | Designation of tin coating weight | Min.average tin coating weight(g/m2) | Former Coating Designation |
| Equal tin coating | 1.4/1.4 | 1.2/1.2 | #15 |
| 2.2/2.2 | 2.0/2.0 | #20 | |
| 2.8/2.8 | 2.45/2.45 | #25 | |
| 5.6/5.6 | 5.05/5.05 | #50 | |
| 8.4/8.4 | 7.55/7.55 | #75 | |
| 11.2/11.2 | 10.1/10.1 | #100 | |
| Differentially Coating | 1.4/2.8 | 1.2/2.45 | #15/25 |
| 2.2/2.8 | 2.2/2.45 | #20/25 | |
| 2.8/5.6 | 2.45/5.05 | #25/50 | |
| 2.8/8.4 | 2.45/7.55 | #25/75 | |
| 2.8/11.2 | 2.45/10.1 | #25/100 | |
| 5.6/8.4 | 5.05/7.55 | #50/75 | |
| 5.6/11.2 | 5.05/10.1 | #50/100 | |
| 8.4/11.2 | 7.55/10.1 | #75/100 |
Features of Tinplate sheet products:
1. Excellent paint adhesion can be used to produce DRD cans and plastic contact tank
2. Excellent heat denaturation temperature baking does not change color
3. Excellent resistance to sulfur
4. Excellent corrosion resistance
5. Alkali resistance excellent more suitable for basic content packaging
The Packaging of Tinplate :
Kunry have perfect packaging for export tinplate to all over the world.
Longitudinal shear--- Roller milling---Degrease---Anneal--Level--Reroll--Tensionleveler--Substrate delivery--Tinning--Coil delivery--Cut to length---Box delivery.
Kunry Tinplate Through the international certification system
Kunry tinplate are exported to many countries ,such as the USA Italy ,Spain,Portugal,Iran ,Egypt,Thailand and the philippines,and get excellent reputation.
Frequently Asked Question:
If you want purchase tinplate coils from kunry please contact with me immediately !
