Low voltage 12 volt hydraulic pump motor brushless dc motor
- 15000 Piece / Pieces per Month
- shenzhen
- Credit Card
-
traction motor GE761,D77/78,GE752,D29
-
Maxon motor
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
-
High torque BLDC tattoo motor 2016RB low-start voltage diameter 20mm tattoo motor long lifespan tattoo motor for tattoo gun
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | Topband | Model Number: | CB1636 |
| Usage: | Other, electric curtain | Certification: | CE, ROHS | Type: | Gear Motor |
| Torque: | 3mNm | Construction: | Permanent Magnet | Commutation: | Brushless |
| Protect Feature: | Totally Enclosed | Speed(RPM): | 17600rpm | Continuous Current(A): | 160mA No Load |
| Output Power: | 3W | Voltage(V): | 12V | Efficiency: | Other, 80% |
Product Description
Low voltage 12 volt hydraulic pump motor brushless dc motor
12 volt hydraulic pump motor picture:
Brief description
1.Low noise, high speed, long lifetime
2.High efficiency: (Low current consumption and low staring voltage)
3.Reliability (Operates more quietly and low inductance)
4.Our company is the first listed company in intellectual control in China
5.We can offer custom-tailor service
6.Low vibration 12 volt hydraulic pump motor
12 volt hydraulic pump motor data
| CB1636 | UNIT | ’001 | ‘002 | ’003 |
| RATED VOLTAGE | V/DC | 6 | 12 | 24 |
| RATED SPEED | RPM | 9600 | 17600 | 11200 |
| NO LOAD SPEED | RPM | 12000 | 22000 | 14000 |
| NO LOAD CURRENT | mA | 160 | 200 | 100 |
| RATED CURRENT | mA | 800 | 1200 | 460 |
| RATED TORQUE | mN.m | 3 | 5 | 5.5 |
| RATED POWER | W | 3.02 | 9.21 | 6.45 |
| MAX EFFICIENCY | % | 65 | 68 | 68 |
| RESISTANCE PHASE TO PHASE | OHM | 1.8 | 2.6 | 13.2 |
| TORQUE CONSTANT | mN.m/A | 4.6 | 5.2 | 16 |
| SPEED CONSTANT | rpm/V | 2000 | 1833 | 583 |
| WEIGHT | G | 40 | 40 | 40 |
Application
Certification
Company Information
Shenzhen Topband Co., Ltd. is one of the biggest company to do the DC Motor and Controller in China, which is established in 1996. Motor division is focusing on coreless motor, general BLDC motor,brushless motor and brushless dc motor controller.Topband was listed in Shenzhen stock change on July 2007, became the first listed company in intellectual control in China, the stock code 002139.
