Help Center101J Wireless Signal Detector
Related Products
-
Mobile Phone Signal Detector With Alarm SystemNegotiableMOQ: 1 Piece -
EST-404A Wireless Scanner DetectorNegotiableMOQ: 1 Piece
-
EST-101F Camera DetectorNegotiableMOQ: 1 Piece
-
EST-101A Cell Phone Signal DetectorNegotiableMOQ: 1 Piece
-
EST-101A GSM Cellphone Signal DetectorNegotiableMOQ: 1 Piece
Specifications
1.Working range: 15meters2.detect the various wireless earphone
1. detect the various wireless earphone exactly.
2.detect and orientation various communication equipment (cellphone, interphone, high-power transmitter inner car, dictagraph, wireless pinhole camera, wireless video communication equipment, homemade communication equipment, radio etc.)
3. Inductive & passive detecting technology, no radiation.
4.withpaste components and integrated circuits for advanced performance, low power and can work continuously for a long time.
5. With intelligent analysis software inside alarm exactly and promptly.
6. The software can upgrade to meet other further requirement.
7. High intensity of signal detecting which can get the slender signal exactly.
8. The inimitable circuit manages the close signal in the equipment which can get the exact orientation in crowd.
9. 8 indicators to show the intensity of the signal
10. With vibration and buzzer for warning choice.
11. Monitoring the conversation of the wireless phone by earphone
3..Specifications
|
1.Detecting frequency range:100-5800MHz 2.Working range: 15meters 3.Working voltage: 12V (built power source) |
|
Power consume:100mW wight:50g Dimension: 100(L)×60(W)×23(H) |
3. Operation
Power On
1. Open the battery cover , put the battery in the correct direction.
2. Press the toggle switch, up for the wireless communications signal detection and the working red indicator is on. When the unit got the signal, the blue indicator is on and the unit will vibrate. You can hear the beeps by earphones.The toggle switch down for wireless video detection, when the unit got the signal, you ca hear the sound by the headphone
3. Sensitivity adjustment, if there is no outside interference signal please adjust the switch to the max (if the blue indicator is on, please adjust switch back till the blue indicator is off )
a. Make yourself to be the centre of the circle, hold the unit and go around the area by 360°. If the blue indicators are flash and not stable that'll be the noise signal instead the wireless signal from a emission source. We can ignore the flash.
b. When you put the earphone on, you may hear the sound somewhere (not the voltaic sound). That means there’s someone using the wireless earphone for the communication. Closer to the signal source, clearer the voice is.
c. Low power indicate when the battery is below 2V, the low power red indicator is on which means the unit need to recharge.
-101J wireless interphone&cellphone signal detector
