Technology Specifications | |
Model |
DZQ-600L/S |
Machine Dimension(mm) |
730×700×1800 |
Sealer Dimension(mm) |
600×10×2 |
Sealer Power Consumption(kw) |
2 |
Pump Capacity(m3/h) |
20 |
Pump Power Consumption(kw) |
0.9 |
Voltage(v) |
110/ 220/ 240 |
Hertz(Hz) |
50/60 |
Production Cycle(times/min) |
2-3 |
Conveyor Adjustment Range(mm) |
0-700 |
Min. Height From Floor to Conveyor(mm) |
350 |
N.W.(kg) |
210 |
G.W.(kg) |
260 |
Shipping Dimension(mm) |
910×820×1900 |
Vertical type multifunction modified atmosphere vacuum packaging machine is a basic external vacuum packaging machine, plus could be fixed gas flush system for inert gas filling or mixed gas filling in the packaging according to customers’ actual requirements. We will supply powder filter according to power’s mesh number if the packing item is powder at customers’ option. Generally heat sealing comes with single sealer, double sealers heat sealing can be chose according to customers’ bags different thickness at customers’ option. This machine comes with an unpowered lift-down conveyor, it can lift and down easily in the adjustment range from 0-700mm according to packing items. This machine has a standard sealer in the length of 600mm, also it is ok to lengthen to 700-1000mm if customers need.
(food vacuum machine,food vacuum packing machine,food vacuum sealing machine,food vacuum sealer,food vacuum packer,vacuum packager...)
Technical Character:
1.Control system: OMRON programmable PLC, text display.
2.Pneumatic system: Taiwan AirTAK pneumatic component
3.External vacuum suction structure: Two cylinders, two suction nozzles.
4.Lift-down conveyor, easy in operation.
5. Heavy moving wheel (with brake): The heavy moving wheel with high bearing capability, which makes customer moving easily
