fiels installable screw type USB connector
- 1000000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Chogori | Model Number: | 34000000-01 |
Application: | Power | Gender: | Male |
Product Description
Specifications
A. The waterproof rating is IP68B. UL,CE,ROHS
The detail description of Chogori USB waterproof connector
The brief introduction of chogori USB waterproof connector
- we have 4 pin USB waterproof connector
- the waterproof rating can be IP66,IP67,IP68 ,it’s all depends on customer’s request
- we can use the cable provided by customers, and we also can purchase cable for our customers.
The specification of USB 4 pin waterproof connector
Push lock USB 4 pin waterproof connector | |||
1 | Model No. | 34000000-01 | |
2 | Material | Connector Body | ABS/PBT/PA66 UL94V-0 1/8” |
3 | Contact | Brass with Gold Plated | |
4 | Sealing | Silica Gel | |
5 | Property | Current Rating | 1.5A |
6 | Voltage Rating | 110V | |
7 | Contact Resistance | <30mΩ | |
8 | Insulation Resistance | 1000MΩ at DC 500V | |
9 | Breakdown Voltage | >AC500V/1minute | |
10 | Temperature Rating | -45°C~+105°C | |
11 | Durability(Plug/Unplug) | 3000 times | |
12 | Waterproof Rating | IP68 | |
13 | Cable Max. Diameter | 2.9~6.3mm | |
14 | Contact Range | 1,2,3,4,5,6,7,8,10,14 | |
15 | Certificate | CCC; CE; ROSH |
The picture of our product(Our connectors can be used in LED industry,comunication industry and so on ,if you have interest in our product, please feel free to contact us, we will provide the excellent quality and reasonable price connectors for you !)
