standard series push lock PCB panel front mount ip68 waterproof connector
- 1 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
- Website Selling Bnc Connector Auto Electrical Wire Connector
- Sell OnlineAutomotive Lock Wire Joint Connector
- OEM/ODM Factory Direct 2Mm Wire To Board Connector
- Experienced Factory Automotive Jst Connector Wire To Wire
- China Professional Automotive 2 Pin Male Female Jst Connector
- Custom Product Wire Spring Socket Connector
Product Details
Place of Origin: | Guangdong, China | Brand Name: | CHOGORI | Model Number: | 22003535-02 |
Type: | RGB | Application: | Power | Gender: | Other, panel mount |
Product Description
Specifications
(1)3pins ,(2)IP68 waterproof grade
(3)CE, 3C,UL
(4)standard panel mount waterproof connector
(5)10A,300V
standard series are used in LED screen, streetlight and power industry, communication industry, marine electron industry, actuating motor industry, and so on.
The advantages of standard series:
- adopt separate design
- increase creep distance
- various connection types
- butt joint easily and reliably
- stop man element
- plug quickly
fit safety design: our connector are CCC UL TUV certified
there are various of connection types, customers have a best choice.Lock bayonet, screw and push lock do coexist.
Number of Contacts | 2 | 3 | 4 | 5 | 6 | 2+4 | 3+4 | 8 | 10 | 12 | ||||||||
Wire Gauge | 0.823mm2 (18AWG) | 0.519mm2(20AWG) | 0.823mm2 (18AWG)*2C/3C 0.519mm2 (20AWG)*4C | 0.519mm2 (20AWG) | 0.34mm2 (22AWG) | |||||||||||||
Panel Thickness | Max. 5.0mm | Max. 5.0mm | Max. 5.5mm | |||||||||||||||
Environmental Protection | IP68 | IP67 | IP67 | |||||||||||||||
Machanical Life | 500 mating cycles | |||||||||||||||||
OperatingTemperature | -45°C -+105°C | |||||||||||||||||
Voltage Rating | 300V | 300V | 125V | 60V | 60V | 60V | 60V | 60V | 30V | 30V | ||||||||
Rated Current (40°C) | 10A | 10A | 10A | 5A | 5A | 10A+5A | 10A+2A | 5A | 2A | 2A |
MORE DETAILS
other information:
Standard series of 5A+8pins standard panel mount waterproof connector (front panel mount, screw mating style)
Material
Connector Body: Nylon+GF UL94V-0 1/16"
Contact: Brass C2680 and C17200 4u"--20u" Gold Plated
Sealing: EPDM
RoHS CE
How to buy?
* confirming Current Rating and Number of Contacts
* confirming Connector and Contact Gender
* confirming Assembly Style
* confirming Mating Style
* confirming Cable OD Size
* Need Waterproof Cover?
Property
Contact Resistance :<10mΩ
Insulation Resistance :≥100 MΩ at DC500V
Breakdown Voltage :≥1000V/1Minute 2.5kV 1.0kV
Temperature Rating :-45~+105
Waterproof Rating :IP68 10m Water 2 weeks
Durability :≥ 3K Plug/Unplug Cycles
Our connectors can also be used in LED display, LED pixel light,LED tube light ,LED wall washer light,LED path light, LED pool light, LED tunnel light,LED panel ,LED liner.
Any questions and comments from you will be very appreciated here.
Contact Us
- Shenzhen Chogori Technology Co., Ltd.
- Contact namealice lee
- Phone0086-755-28227702
- AddressBuilding E, Zhonggangxing Industrial Zone, ZhangGe Village, Guanlan, LongHua New District Shenzhen,Guangdong
