Help CenterAD-824 RFID Inlay
US$ 0.06 - 0.2
MOQ: 1000 Units
Key Specifications
Get Latest Price
Material:
PET
Usage:
Price Tags
Type:
RFID
Payment & Shipping
Payment Methods:
Port of Shipment:
China or Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheap AD827 WET Inlay (UHF RFID Tag)US$ 0.15 - 0.2MOQ: 21000 Pieces -
The Best Selling AD232 Dry Inlay (UHF RFID Tag)US$ 0.1171 - 0.18MOQ: 21000 Pieces
-
Low Cost AD827 Dry Inlay (UHF RFID Tag)US$ 0.119 - 0.18MOQ: 21000 Pieces
-
The Best Selling AD232 Long Reage Range Wet Inlay (UHF RFID Tag)US$ 0.13 - 0.15MOQ: 21000 Pieces
-
AD-730 InlayUS$ 0.21 - 0.6MOQ: 1000 Units
Material
PET
Usage
Price Tags
Type
RFID
Feature
Anti-Counterfeit
Custom Order
Accept
Place of Origin
United States
Brand Name
Avery Dennison RFID
Model Number
AD-824
AD-824 RFID Inlay
The AD-824 UHF RFID Inlay is a stackable inlay. It incorporates a breakthrough antenna design that enables high read rates in item level applications where tags may be stacked within a fraction of an inch of each other allowing you to tag items in close proximity while retaining good read rates. Utilizing the G2x chip platform, the AD-824 delivers more memory, has a pre-loaded serial ID number and delivers strong read ranges. The AD-824 is EPCglobal C1G2 1.0.9 certified and compliant to EPCglobal C1G2 1.1.0 and ISO 18000-6C. The AD-824 provides reliable global operational capability by reducing variation in read range performance across the 860 – 960MHz UHF band. This enables one inlay to be used regardless of geographic deployment.
The AD-824 performs well on mild dielectric materials and is wide band:
Features:
- Stackable inlay - Breakthrough antenna design enables high read rates in item level applications where tags may be stacked within millimeters of each other
- Incorporates G2X chip platform with unique 32 bit serial number, factory programmed and locked
- 240 bits EPC memory with an additional 512 bit user memory option
- EPCglobal C1G2 1.0.9 certified, compliant to EPCglobal C1G2 1.1.0 and ISO18000-6C
- Available in high yield / high capacity rolls
- Electronic Article Surveillance (EAS) custom command
- Read protect custom command
- Calibrate custom command
Advantages:
- Inlay circuit is tuned for global frequency operations across many dielectric substrates to create an all-purpose tag retaining good performance across a wide variety of materials and applications
- Unique 32 bit serial number, factory programmed and locked, eliminating the need to program tags downstream with unique numbers
- Extra user memory enables more applications that require additional data beyond the EPC number such as life cycle verification, warranty tracking, expiry dates, work in process, routing or quality data
- Tight pitched densely arrayed inlays allows you to pack more inlays on a roll reducing roll change-outs and labor
- The EAS security feature allows the tag to be used as an anti-theft device by sending an alarm signal to a reader if the tag has not been deactivated by the business application software when moving through a reader gate
- Read protection helps to prevent unauthorized memory access by requiring a password handshake with the reader and can protect potentially sensitive data in the memory
- Calibrate custom command send a continuous data stream that enables easier tag to reader communications evaluation and application performance fine tuning
Benefits:
- Stackable inlay - Breakthrough antenna design enables high read rates in item level applications where tags may be stacked within millimeters of each other allowing you to tag items in close proximity to each other and retain good read rates
- Strong read ranges and read rates improve system data reliability and increases efficiency, throughput. Reduces costs associated with missing data or line stoppages
- Additional user memory allows you to configure your tag data for custom applications, extending the utility of the EPC solution to support additional efficiency and service improvement programs like carrying a maintenance record, WIP updatable record or product expiration dates for asset utilization management
- Helps keep shelves stocked, improves accuracy in inventory counts, security features reduced theft and loss, thereby reducing operational costs and increasing sales lift
Markets and Applications:
- Supply Chain carton, pallet and item level tagging
- Retail
- Media Management
- Industrial / Factory AIDC Asset tracking
