Cone Type Marine Dock Rubber Fender
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Anter | |
| Model Number | AT-RF029 | Part | Other |
Product Description
Super Cone Fenders
Super Cone fenders are the 3rd generation of cell fenders,with optimal performance and efficiency.The conical body shape makes the cone fender very stable even at large compression angles.They come in a wide range of standard sizes,can meet multi-berthing conditions.
Features
1. BV PIANC standard approved
2. Outstanding energy absorption
3. High energy absorption
Specifications:
| Specification | ||||||||
| H (mm) | ØU | ØS | ØP | ØD | n | n-Ma | n-Ød | h |
| 500 | 425 | 325 | 675 | 750 | 4 | M24 | 30 | 25 |
| 600 | 510 | 390 | 810 | 900 | 6 | M24 | 30 | 27 |
| 700 | 595 | 455 | 945 | 1050 | 6 | M30 | 38 | 32 |
| 800 | 680 | 520 | 1080 | 1200 | 6 | M36 | 44 | 36 |
| 900 | 765 | 585 | 1215 | 1350 | 6 | M36 | 44 | 41 |
| 1000 | 850 | 650 | 1350 | 1500 | 6 | M42 | 56 | 45 |
| 1100 | 935 | 715 | 1485 | 1650 | 6 | M42 | 50 | 50 |
| 1150 | 998 | 750 | 1550 | 1725 | 6 | M42 | 56 | 52 |
| 1200 | 1020 | 780 | 1620 | 1800 | 8 | M42 | 50 | 54 |
| 1300 | 1105 | 845 | 1755 | 1950 | 8 | M48 | 60 | 59 |
| 1400 | 1190 | 930 | 1890 | 2100 | 8 | M48 | 60 | 66 |
| 1600 | 1360 | 1060 | 2160 | 2400 | 8 | M48 | 70 | 72 |
| 1800 | 1530 | 1190 | 2430 | 2700 | 10 | M56 | 76 | 78 |
Remark: Different sizes of super cone fender can be made according to customers' request.
