DVR Lightning Protector, Video Surge Protector
- 5000 Set / Sets per Month
- Shenzhen
- T/T
Product Details
Place of Origin: | Henan, China | Brand Name: | CY | Model Number: | CY-BL301, BL302, BL303, BL301WL |
Product Description
Surge Protection Device
1. Single Video Surge Protector CY-BL301
Function & Application
This device CY-BL301 is used to protect video signal systems from the damage caused by overvoltage or static discharge, etc. by lightning strike.
Features
1. Built-in protective semi-conductive components, high through flow rate, low limiting voltage, short response time and reliable performance.
2. Wide frequency band, little insertion loss, and low standing-wave ratio.
3. Exquisite appearance, easy for installation.
Technical Data
Nominal Voltage UN | 5V | Insertion Loss | Less than 0.3dB |
Max. Continuous DC Voltage UC | 8V | Response time | Less than 1ns |
Max. Through Flow Rate | 5KA | Impedance | 75Ω |
Max Speed VS | 10M | Interface | BNC |
Working Conditions | Temperature Range: -25~+85 Celcius Degree Humidity Range: 5%~95% |
Function & Application
CY-BL302 is used to protect the power supply and video devices of AC/DC-powered surveillance cameras from surge damage caused by sudden increase of potential difference between different devices when there is induction lightning strike.
Technical Data
Video Parameters | Working Voltage | 8V |
Max.Continuous WorkingVoltage | 15V | |
Max.Through Flow Rate | 10KA | |
Max.DataTransmission Speed VS | 20M | |
Insertion Loss | ≤0.3dB | |
Response time | 25ns | |
Impedance | 75Ω | |
Interface | BNC | |
Electric Power | Working Voltage | AC24/DC12 |
Max.Continuous WorkingVoltage. | 40V | |
Max.Through Flow Rate | 10KA | |
Response time | ≤1ns | |
Interface | terminal(L,N) | |
Working Environment | Working Temperature | -25°C~75°C |
Working Humidity | 5%-95% non- condenscending |
3. Surge protector for Video, Power and Data CY-BL303
Function & Application
CY-BL303 is used to protect the power supply, video and data devices of AC/DC-powered surveillance cameras from surge damage caused by sudden increase of potential difference between different devices when there is induction lightning strike.
Features
1. Three protected lines, no interference with each other and reliable performance.
2. Wide frequency band, little insertion loss, and low standing-wave ratio.
3. Exquisite appearance, easy for installation.
Technical Data
Video Parameters | Working Voltage | 8V |
Max.Continuous WorkingVoltage | 15V | |
Max.Through Flow Rate | 10KA | |
Max.DataTransmission Speed VS | 20M | |
Insertion Loss | ≤0.3dB | |
Response time | 25ns | |
Impedance | 75Ω | |
Interface | BNC | |
Electric Power | Working Voltage | AC24/DC12 |
Max.Continuous WorkingVoltage. | 40V | |
Max.Through Flow Rate | 10KA | |
Response time | ≤1ns | |
Interface | terminal(L,N) | |
Data Parameters | Data Type | RS485(Simplex, half-duplex) |
Working Voltage | 8V | |
Max.Continuous WorkingVoltage. | 15V | |
Max.Through Flow Rate | 10KA | |
Max.DataTransmission Speed VS | 20M | |
Response time | ≤1ns | |
Interface | terminal (+,-) | |
Working Environment | Working Temperature | -25°C~75°C |
Working Humidity | 5%-95% non- condenscending |
4. Multi-channel Video Surge Protector
5. Network Surge Protector CY-BL301WL
Function & Application
This device CY-BL301WL is used to protect equipment of Ethernet 10 Base or 100 Bas T (like network Card, Ethernet Switch, HUB, Router, etc.) from the damage caused by overvoltage or static discharge, etc. by lightning strike.
Features
1. High through flow rate, low limiting voltage, short response time and reliable performance.
2. Wide frequency band, little insertion loss, and low standing-wave ratio.
3. Exquisite appearance, easy for installation.
Technical Data
Nominal Voltage UN | 5V | Insertion Loss | Less than 0.5dB |
Max. Continuous DC Voltage UC | 6.8V | Response time | Less than 1ns |
Max. Discharge Current | 10KA | Transmission Rate | 100Mbps |
Nominal Discharge Current | 5KA | Interface and Protected Lines | RJ45 (A: 1/2, 3/6 B: 1.2.3.4.5.6.7.8) |
Others | Temperature Range: -40~+80 °C Resdual Voltage: <5V |
