Hsgd Led Display Led Display Outdoor With CE Certificate

Name: Hsgd Led Display Led Display Outdoor With CE Certificate
Brand: haisheng
SKU: 121139751
Availability: InStock

Negotiable MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

haisheng

Model Number:

HSGD-O-F-P10

Shenzhen Haisheng Led Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name haisheng

Model Number HSGD-O-F-P10

signage panel

advertising signsprogrammable led display screen

Specification:

Item	Discription		HSGD-O-F-P10
1	Unit Module	LED Style	LED lamp DIP346
2		Classification	Real pixel Full-color
3		Physical pixel pitch	10mm
4		Pixel configuration	1R1G1B
5		Module Size	160*160mm
6		Resolution of Module	16*16
7		Power Consumption of Module	≤24W
8		Physical pixel Density	10,000/ sq.M
9	Major Technology Parameter	LED per sq. meter	30,000
10		Max Power Consumption	920W/sq.M
11		Resolution of cabinet	64x48
12		Size of Cabinet	640*480mm
13		Weight of Cabinet	32Kg waterproof
14		Brightness	≥8,500cd / sq.M
15		Frame of Frequency	≥60Hz
16		Refresh Rate	≥600Hz
17		Driving Method	1/4 Scan Constant Current Driving
18		Viewing angle	Horizontal: ≥120°; Vertical: ≥60°
19		Colors	Each color ≥16,384grace
20		Brightness adjustment	Automatically:256 levels for each color (R,G,B) Manually: 100 levels for each color (R,G,B)
21		Ingress protection	Front: IP65; Rear: IP43
22		Voltage	220V±10% or 110V±10%
23		Mean Time Between Failure	>5000 hours
24		Life-span	>100,000 hours
25		Operating environment	Temperature: -20°C-60°C; Humidity: 10%-90%RH
26		Input Signal	RF, S-Video etc.
