US$ 1.57 - 10.22 MOQ: 25 Pieces
Key Specifications
Get Latest Price
LED Light Source:
2835
Warranty(Years):
2
Input Voltage(V):
AC 85V to 265V
Contact Supplier Request Quote Chat Now
Zhongshan Sanhe Electronic Technologhy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
zhongshan/shenzhen/guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 2835
Warranty(Years) 2
Input Voltage(V) AC 85V to 265V
Lamp Power(W) 18
Lamp Luminous Flux(lm) 1800
Lamp Luminous Efficiency(lm/w) 102
Color Temperature(CCT) Pure White
Working Temperature(℃) -20, 40
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
IP Rating IP33
Certification CE
Place of Origin Guangdong, China
Brand Name sanhe
Model Number T8





Although it is very common, but you can't live without it.

zhongshan led lighting t5 Led tube 1500mm CE and ROHS China supply

The rate that this theme artistic conception reflects is higher, the artistic grade that its lamp acts the role is higher. This ability is desirable practice.



zhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supply

zhongshan led lighting t5 Led tube 1500mm CE and ROHS China supply

1. Power Specification

1.1  Input Electrical Characteristics

Input voltage range

85V to 265V  AC

Frequency range

50Hz/60Hz±5%

Input Power

18W

PF

0.98

Efficiency(full load)

92%min at 220V AC(non isolating)



1.2 Output Electrical Characteristics

Output current

230mA±3%

output current rise time

≤30 mS

Output Voltage range

36V-80V  DC

Output Short Circuit Protection

YES

















2. Tube Characteristics



Luminous Flux Output

>1550 LM(milky white PC cover)

>1800LM(transparent PC cover)

Rendering Index

≥70

Power

18W,14W,9W

Beam Angle

160±5Degrees

Color Temperature

3000K~3500K/4000K~4500K/6000K~6500K

Light Source:

SMD-2835LED-60mA-3.2V  96PCS

PCB

Al base board  1170*9.5*1.0mm-4B24C

Aluminum

Aviation grade aluminum

PC Cover

milky white PC cover  / transparent PC cover

Total Size:

L1198×W28×H32±1mm

Weight:

275±5g

Warranty

2 years

Certification

CE, ROHS

Lifespan

50000hrs

carton size

1245*215*215mm

Packing quantity

25PCS



zhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supply

zhongshan led lighting t5 Led tube 1500mm CE and ROHS China supplyzhongshan led lighting t5 Led tube 1500mm CE and ROHS China supply

There is no doubt that the relationship between people and light is an eternal topic."People saw the lamp, I saw the light”. It is the classic of the words has changed countless designer understanding of the lamp. Shadowless lamp is the highest level of the lamps also the highest embodiment of the humanization lighting,There is no any trace of the common lamps in the room so that people can feel the brightness but can't find the light source .It reflects the humanization design of the perfect combination with light and human life.
