Solar Tube Well Pump in District Qilla Saifullah Baluchistan
US$ 6,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Green Answer
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solar Powered Pumps for Water BoreholesUS$ 19,000 - 22,000MOQ: 1 Set -
Solar Powered Submersible Water PumpsUS$ 6,000 - 8,000MOQ: 1 Set
-
Solar Deep Well Pump for VineyardsUS$ 74,000 - 80,000MOQ: 1 Set
-
Solar Borehole Puping System for UgandaUS$ 2,200 - 3,000MOQ: 1 Set
-
Solar Deep Well Pump in AlgeriaUS$ 8,000 - 10,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
Green Answer
Model Number
SP3K
Material
Other, Steel
Feature
Solar and disel generaror powered
Diameter
2 inch
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
-
Features:
AC water pump:
Power: 3kW
Voltage: 3-phase 380V AC, 50Hz
Type: multi-stage centrifugal submersible pump
Series: water cooling and reinforced motor suitable for solar power
Max. flow: 70m3/hour
Max. head: 207m
Outlet: 1.25/1.5/2/2.5/ 3/4 inches
NEMA standard: 96mm
Diving depth: ≤50m
Materials:
Water outlet: 304 stainless steel
Impeller: 304 stainless steel
Pump body: 304 stainless steel
Motor casing: 304 stainless steel
Motor shaft: 304 stainless steel
Screw: 304 stainless steel
Upper guide bearing, thrust bearing base: cast iron, can be updated to be stainless steel with extra cost if needed
Water quality: sand content (weight ratio) in water should not exceed 0.01%, chlorine content should not be over 400mg/L
Max average daily water supply: 400m³ @ 5.5kWh/m²/day
Warranty: 18 months, extend to 2-year warranty optional with extra cost
Advantages: up to 15yrs lifetime, working is reliable & stable
Controller and inverter:
Power: 3.7kW
Input voltage: 330-710V
Output voltage: AC, 3-phase 380V
MPPT voltage: 450-600V
Max MPPT efficiency: ≥97%, soft start/stop
Warranty: 2-year, extend to 3-year warranty optional with extra cost
Protection:
Over-current, over-voltage, over-speed, over-temperature
Reverse polarity
Dry water/phase failure protection
Advantages: high MPPT efficiency function, GMS remote control, auxiliary diesel power/3 phase AC electricity hybrid power transfer-switch controller, water flow control regulator, soft start/stop
Solar panel reference:
Power: mono/poly, totally about 4.5kW
Positive tolerance: +0/5W
Products warranty: 5 years
Performance warranty: 90%/10 years, 80%/25 years
Mounting system:
Type: fixed mode/pillar manual tracking/slanting uniaxial tracking
Foundation: concrete pouring
Installation type: 6 pieces/array and vertical
Warranty: 5 years
Material: hot-dip galvanized
Combiner box: N/A
Accessories: PV cables, water pump cables, water level detective sensor, cable sleeves, pipeline, flange, riser pipe
Quantity of accessory materials are based on actual design
Applications:
Ecological irrigation
Solar drought control
Solar living water supply
Agriculture irrigation
Solar desert control
Solar seawater desalination system
Solar city water landscape
Pasture irrigation
-
Features:
Packaging & Shipping
Performanc Curve
Functional Diagram
FAQ
Solar AC Pump VS DC
| Factor | Solar AC Pump | Solar DC Pump |
Cost |
Less when compared to DC | High |
|
Ability to run on Mains during nights/ when solar absent |
Yes | NO |
| Installation, maintenance & servicing | Easy | Difficult |
| Aviable application | Submersible/monoblock/open-well | Most submersible only |
| Reliablitiy | Good | Poor |
