Home > Electrical & Electronics > Electronic Tube & Transistor > Rectifier Diode > High Brightness Mcd 12000 Water Clear 5mm Green Led Diodes

High Brightness Mcd 12000 Water Clear 5mm Green Led Diodes

High Brightness Mcd 12000 Water Clear 5mm Green Led Diodes thumbnail-1
High Brightness Mcd 12000 Water Clear 5mm Green Led Diodes thumbnail-2
High Brightness Mcd 12000 Water Clear 5mm Green Led Diodes photo-1
High Brightness Mcd 12000 Water Clear 5mm Green Led Diodes photo-2
Negotiable MOQ: 1 Bag (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
China
Model Number:
5mm green
Contact Supplier Request Quote Chat Now
Henan Tresun Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name China
Model Number 5mm green
Type LED
Package Type Surface Mount
Max. Reverse Voltage 3.0~3,4v

5mm leds water clear lense with flange



Features:

water clear single color green

High bright output

Low power consumption

High reliability and long life/light decal very slow..



Descriptions:

Dice material:GaInN

Emitting Color:Super Bright white

Device Outline:φ5mm Round Type

Lens Type:Water Clear





Specification:



1.Flux: 1800~3000mcd

2.Wavelength: 588-594nm

3. Forward Voltage: 3.0-3.4V

4.Beam Angle:120degree around



4.8mm helmet led
Part No. Intensity Angle (Degree) CCT available Voltage( V)
FD-5HTW-1 1800-2000mcd 100-120deg From 2500 to 20000K 3.0-3.4V
FD-5HTW-2 2000-2500mcd 100-120deg 3.0-3.4V
FD-5HTW-3 2500-3000mcd 100-120deg 3.0-3.4V
Part No. Color Angle (Degree) Wavelength Voltage( V)
FD-5HTR-1 Red  100-120deg 620-625nm 1.9-2.4V
FD-5HTY-1 Yellow 100-120deg 588-595nm 1.9-2.4V
FD-5HTG-1 Green 100-120deg 520-525nm 3.0-3.4V
FD-5HTB-1 Blue 100-120deg 460-470nm 3.0-3.4V


4.8mm  Straw hat led
Part No. Intensity Angle (Degree) CCT & Wavelength Voltage( V)
FD-5STW-1 1800-2000mcd 100-120deg From 2500 to 20000K 3.0-3.4V
FD-5STW-2 2000-2500mcd 100-120deg 3.0-3.4V
FD-5STW-3 2500-3000mcd 100-120deg 3.0-3.4V
Part No. Color Angle (Degree) Itensity Voltage( V)
FD-5STR-1 Red  100-120deg 620-625nm 1.9-2.4V
FD-5STY-1 Yellow 100-120deg 588-595nm 1.9-2.4V
FD-5STG-1 Green 100-120deg 520-525nm 3.0-3.4V
FD-5STB-1 Blue 100-120deg 460-470nm 3.0-3.4V









5mm round Red color in water clear lens
Viewing angle in 15-20degree
Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TR-1  4000-6000 15-20 620-630 1.9-2.4
FD-5TR-2 6000-8000 15-20 620-630 1.9-2.4
FD-5TR-3 8000-12000 15-20 620-630 1.9-2.4
FD-5TR-4 12000-18000 15-20 620-630 1.9-2.4
FD-5TR-5 18000-20000 15-20 620-630 1.9-2.4
FD-5TR-6 20000-23000 15-20 620-630 1.9-2.4
FD-5TR-7 23000-25000 15-20 620-630 1.9-2.4
5mm round Yellow color  in water clear lens
Viewing angle in 15-20degree
Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TY-1  5000-7000 15-20 588-595 1.9-2.4
FD-5TY-2 8000-10000 15-20 588-595 1.9-2.4
FD-5TY-3 10000-15000 15-20 588-595 1.9-2.4
FD-5TY-4 18000-22000 15-20 588-595 1.9-2.4
FD-5TY-5 22000-25000 15-20 588-595 1.9-2.4



5mm round Amber color  in water clear lens
Viewing angle in 15-20degree
Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TA-1  5000-7000 15-20 600-610 1.9-2.4
FD-5TA-2 8000-10000 15-20 600-610 1.9-2.4
FD-5TA-3 10000-15000 15-20 600-610 1.9-2.4
FD-5TA-4 18000-22000 15-20 600-610 1.9-2.4
FD-5TA-5 22000-25000 15-20 600-610 1.9-2.4



5mm round Whitecolor  in water clear lens
Viewing angle in 15-20degree
Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TW-1  13000-16000 15-20 Warm white (2500-5500K) Pure white (5500-6500K) Cool white (6500-10000K) 3.0-3.4
FD-5TW-2  16000-18000 15-20 3.0-3.4
FD-5TW-3  20000-23000 15-20 3.0-3.4
FD-5TW-4  25000 15-20 3.0-3.4
FD-5TW-5 25000mcd ( Perfect light version ) 15-20 3.0-3.4



5mm round Greencolor  in water clear lens
Viewing angle in 15-20degree
Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TG-1  20000-23000 15-20 520-530 3.0-3.4
FD-5TG-2  23000-25000 15-20 520-530 3.0-3.4
FD-5TG-3  25000-28000 15-20 520-530 3.0-3.4
FD-5TG-4  28000 Perfect light version 15-20 520-530 3.0-3.4



5mm round Bluecolor  in water clear lens
Viewing angle in 15-20degree
Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TB-1  6000-8000 15-20 460-470 3.0-3.4
FD-5TB-2  10000-15000 15-20 460-470 3.0-3.4
FD-5TB-3  13000-15000 15-20 460-470 3.0-3.4
FD-5TB-4  15000-18000 15-20 460-470 3.0-3.4



5mm round Purple color  in water clear lens

Part No. Intensity at 20mA ( mcd ) Emitting Angle ( Degree ) Wavelength ( nm ) Voltage ( V )
FD-5TUV-1  2000-3000 / 400-410 3.0-3.4
FD-5TUV-2 3000-5000 / 400-410 3.0-3.4
FD-52TUV-1  1500 / 390-400 3.0-3.4
FD-53TUV-1  800 / 380-385 3.0-3.4
FD-54TUV-1  300 / 365 3.0-3.4
FD-55TUV-1  1000 / 410-420 3.0-3.4
FD-356TUV-1  800 / 430-440 3.0-3.4





Product Views:

Why Choose us?



Professional service



Quick and precisely answers to your inquiry.

Professional staff can answer your question precisely and quickly.

We will consider time lag and try to work on customers time. We will make sure on line more than 12hours each day by return.





Profits your business



Same cost we can assure best quality, save your cost and add your profit.

It helps win your competitor not only on price but aslo on quality.



Make your business success more fastly



We can accept customer made, OEM service.

With our well-defined quality requirements and engineers effort, you can get the product as your request easily and fastly, which helps you win more valuable customers.

It will reduce your steps toward to success business.

Also we put some stocks for some hot items and keep stepping with the new information and technolgoy.

Our staffs will Updated new items to you frequently to increase your sales as well.





Delivery:





1, Normally we prefer to dispatch small order by DHL/FedEx/TNT/UPS. Here we also guarantee on time delivery and if necessary, we will provide you the best logistics solution for the goods to reach at your location on time.

2, FCL - Full Container Loading

3, LCL - Less Container Loading

We have large stock of Led components, resistors and capacitors, diodes in normal values for both domestic and oversea market.
Welcome to enquiry us and sample is available upon request, thanks.
