96W Led Driver 2660mA Output Compact & Efficient Durabe Quality

96W Led Driver 2660mA Output Compact & Efficient Durabe Quality thumbnail-1
96W Led Driver 2660mA Output Compact & Efficient Durabe Quality photo-1
Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
tresun/oem
Model Number:
LZA96W-36-C2660
Contact Supplier Request Quote Chat Now
Henan Tresun Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name tresun/oem
Model Number LZA96W-36-C2660
Output Power 51 - 100W
Output Type Single
Input Voltage Other, 90-305vac
Output Voltage 22-36Vdc
Output Frequency 47-63Hz
Output Current 2660mA

96W constant current led driver from professional factory,  for LED  Panel Light, LED Grille Light, led parlight, spotlight

Product type: constant current drive, compact and efficient

Application Scope: LED Panel Light, LED parlight, LED Grille Light

Product size: Size: 161mm(L)×61mm(W)×38mm(H)

Warranty: 3 years



Constant Current

Input Voltage

Vac

 Power Factor

Output  Voltage

 Vdc

Constant Current

 mA

Current Acuracy

   %

 Typical Efficiency Location
LZA96W Series @120v @230v
LZA96W-274-C0350 90~305 0.99 0.92 165-274 350 ±5 92 Indoor
LZA96W-213-C0450 90~305 0.99 0.92 128-213 450 ±5 92 Indoor
LZA96W-137-C0700 90~305 0.99 0.92 82-137 700 ±5 91 Indoor
LZA96W-92-C1050 90~305 0.99 0.92 55-92 1050 ±5 91 Indoor
LZA96W-69-C1400 90~305 0.99 0.92 42-69 1400 ±5 90 Indoor
LZA96W-54-C1750 90~305 0.99 0.92 33-54 1750 ±5 90 Indoor
LZA96W-48-C2000 90~305 0.99 0.92 29-48 2000 ±5 90 Indoor
LZA96W-39-C2450 90~305 0.99 0.92 24-39 2450 ±5 90 Indoor
LZA96W-36-C2660 90~305 0.99 0.92 22-36 2660 ±5 89 Indoor
LZA96W-34-C2800 90~305 0.99 0.92 20-34 2800 ±5 89 Indoor
LZA96W-30-C3150 90~305 0.99 0.92 18-30 3150 ±5 88 Indoor
LZA96W-24-C4000 90~305 0.99 0.92 15-24 4000 ±5 88 Indoor



 Product details:

LZP96W Series, led constant current drivers

1. Drive Mode: Constant Current

2. Technology: Single-stage PFC technology, PSR

3. Output Power: 96W Max.

4. Input Voltage: 90 to 305VAC,47-63HZ

5, Number of output: single

6. Output Voltages: 15~ 274Vdc

7. Output Currents: 350mA - 4000mA

8. Safety: EN61347, J61347 (H20), UL8750, CSA C22.2

9. EMC: EN55015, J55015 (H20), FCC 47CFR Part 15 Class B

10. Comply with PSE, CE & CCC

11. RoHs compliant;

12. Plastic Shell, Silicone Potting, Tc 120°C Maximum;

13. Compact, Lightweight Design;

14. Water Resistant and Dust Proof Design: IP66, NEMA 13, for Dusty, Damp, Wet Locations;

15. Standard electrical box for installation;

16. Active Power Factor Correction technology to reduce power consumption;

17. Safety Isolation between Primary and Secondary.

18. Surge Immunity (Lightning Protection): Comply with EN61000-4-5, AC line to line 1000V



Product parameters:

1. Operating Temperature: −30 to +60°C,

2. Storage Temperature: −40 to +85°C;

3. Humidity (non-condensing): 5% to 95%RH;

4. Cooling: Convection;

5. Vibration Frequency: 5 ~ 55HZ/2g, 30 minutes;

6. Impact Resistance: 1g/S;

7. MTBF@40°C: 400,000 hours @ Full Load per MIL-217 Notice 2.;

8. LIFE@25°C: 70,000 hours @ Full Load per MIL-217 Notice 2.;

9. Maximum Input Current: 0.18A (@ 120V, full load);

10. Input Surge Current: <10A (25°C, 230V, cold start);

11. CISPR 22 CLASS B, CISPR 14-1 CLASS B,



                 EN61000-3-2 & EN61000-3-3 Class C,



                 GB19510.14-2009, GB19510.1-2009,



                 GB17743.1-2007, GB17625.1-2003


12. Constant Current Regulation: ±3%, Over Input Line Variation;

13. Load Regulation Accuracy: ±3%;

14. Output Current Ripple: < ±30% ;

15. Leakage Current: 400uA typical; Hold up time: half cycle

16. Standby Power: <0.4W@120V, <0.8W@230V, <1.0W@277V;

17. Protection: Output over-voltage protection;

                      Output over-current protection;

                      Output short circuit, auto-recovery;

18. Lightning & transient protection built in.
