long timber plank vacuum dry kiln equipment high frequency
| Model GZ-4.0III-DL timber plank vacuum dry kiln equipment |
LOOK! the following is high frequency vacuum drier/dryers simple mode introduction.
Model |
GZ-8.0III-DL |
Capacity |
8.64 CBM |
Out Dimension (mm) |
L7600xW2000xH2090 |
Inside dimension (mm) |
L6800xW1750xH1750 |
Timber cart (mm) |
L6000xW1200xH1200 |
Max Length of Wood |
6m |
High Frequency |
6.78MHz |
Input Power |
40KVA |
Oscillation power |
30KW |
Vacuum pressure |
-0.093MPa |
Weight(kg) |
9000 |
Packing |
40HQ |
Kiln Temp |
Vacuum kiln Drying temperature: ≤90°C |
Moisture |
From 90% to 6% ,could be setting as per-request |
Drying time |
2-7 days |
Application |
Apply for all hardwood species |
| Three main parts of timber plank vacuum dry kiln equipment |
1) High frequency generator
2) Vacuum timber dryer oven
3) Cooling tower
Descrption & applicable scope of timber plank vacuum dry kiln equipment
A: High frequency vacuum drying kiln equipment is a relatively small and fast drying equipment
B:Applicable to thick hardwood or wood drying, solves the hardwood or large section of wood drying after deformation and cracking problems, because of its small volume and short cycle drying characteristics, especially suitable for solid wood furniture factory or wood processing manufacturers Wood drying or back late the water drying.
Working principle of timber plank vacuum dry kiln equipment
Using high frequency electric field is used as a heating source, even electric field radiation in the wood, and penetrates the wood directly on the water for heating, and the vacuum water absorption to accelerate water discharge.
Advantages of timber plank vacuum dry kiln equipment
1: Short drying cycle
2: Good drying effect
3: Easy Operation
4: Energy Saving
5: Cost-Effective
Shipping: within 10-20 days.
Our engineer will install all parts for buyers, the buyer can use it directly when the timber dryer machine reached.
Sample: we can provide free brochures to customers.
Warranty date: all kinds of vacuum dryer machine can be ensured 1 year.
Customer service: If there were something wrong during this warranty, our engineer could be available to oversea to repair it freely.
Packing & shipment
1.Plastic and foam packing, fixed by wood pallet, it is packed in 40 feet container.
2.by sea transport
Henan dingli drying equipment co.,ltd
1.We are Henan Dingli Drying Equipment Co.,Ltd, locate at No.59,Dongda Street, Guancheng Dist., Zhengzhou, China. we are professional manufacturer in new energy and biomass fuel ewuipment and have been 20 years experience.
2.our main equipment is drying machine, which devided into rotary dryer and HF wood vacuum dryer machine.
3.we are able to design suitable for your machine with your demands! welcome to visit our factory!
The mentioned above just used for long timber plank vacuum dry kiln equipment high frequency , if you want to know more details, welcome to contact me!
