HJD42
Clean type LED Light (Tube Type)
Utility model patent number:20162048381
Appearance patent number:2016301997044
Anti-corrosion,Waterproof,Dustproof,Shockproof
1. This product is applied to lighting in the marine, military, stadium, public railway, tunnel, airport, station, dock, ship, power plant, factory, common ditch, cold shortage, urban landscape and so on.
2,Using the thechnology of the invention patent, the automatic cycle pressure technology of the metal explosion-proof enclosure is adopted, and no welding structure is dominan. The strength of the technology is improved by 30% compared with the traditional processing technology.(The technologies used in satellites, missiles, aircraft processing)
3,This product is formed by the combination of stainless steel 316LL and PC materials,which has good corrosion resistance, impact resistance, cold resistance. The external of the product adopted clean and smooth design, which has a good dust effect.
4,Configuring LED strip light source, unidirectional lumine scence, and light is uniform and soft, light effect>100lm/W,Ra>80,and it has long service life. It also energy saving and environmental protection.
1,Basic parameter
Model |
Voltage(AC) |
Luminous flux |
Power(W) |
External diameter(mm) |
Length(mm) |
HJD42 |
AC220 50/60Hz |
≥100lm/W |
60,50,40 |
137×124 |
640 |
30,20,10 |
117×104 |
557 |
2,Shockproof level:Level D
3,Protection level:IP68
4,Anti-corrosion level:WF2
5,Introducing device:M20×1.5,Cable outside diameter 6-12mm
6,Terminal:The wire can be connected when it is less than or equal to 2.5mm2
Carton box /wooden case with pearl cotton. Or according to customer's requirement.
1. Design & Engineering
A.Experienced and skilled team of designers including PROE and CAD designers; 10 years explosion proof products’ experience has the capacity to deliver outstanding designs for your project.
B. Simple design service is free of charge to all clients to ensure customer.
C. We look forward to delivering exceptional designs and advice for your project.
2. How to buy your ideal products?
A. You can provide us your drawings, requirements; and we will produce led flood light as your drawing. Or we can design as your requirements if you do not have a clear plan.
B. According to products description, choose what you needs; any questions, please contact with us at anytime.
3. How to pay?
A.T/T and L/C at sight are acceptable; T/T will be more appreciated 30% deposit before producing, 70% balance before loading by T/T.
B.Other terms of payment, contact with us, reach an agreement.
4. What is the delivery time?
A. It depends on order quantity.Generally, the delivery time will be within 5 to 10 days.
5. Package information
A.For inner packing and outer box are made as per international standards, and we can make special designed for you if need.
B. If necessary,will be packed in plywood case to avoid any damage and convenient to transport.
6. How long to make a sample?ls it free?
A. 7 DAYS depending on the sample’s complexity.
B. Normally, our sample is free.Pay the charge in advance, after completed 10 PCS(Order quantity depend on the different products.) order, return the sample charge.
7.What’s the shipping documents?
A. Instruction
B. Factory inspection report
C. Warranty
D. Others as your requirements
