Specification:
TOM-TK6920 Top quality floor type low cost multi spindle boring machine with Spindle dimater 200mm
1. Max. Column travel(X): 10000mm (or more)
2. Max. headstock travel (Y): 4000mm(optional 5000, 6000)
3. Max. Ram travel(Z): 1200mm
| MODEL | UNIT | TOM-TK6213 | TOM-TK6216 | ||
| HEADSTOCK | Spindle dimater | mm | 130 | 160 | |
| Quill diameter | mm | 221.44 | 260 | ||
| Taper(7:24) | -- | ISO50 | ISO50 | ||
| Too shank | -- | JT50/ OPTIONAL BT50 | JT50/ OPTIONAL BT50 | ||
| Pull stud | -- | LD—50D/ OPTIONAL P50T-I | LD—50D/ OPTIONAL P50T-I | ||
| Spindle speed | rpm | 7~1500 | 7~1500 | ||
| (3 steps hydraulic stepless) | |||||
| Main motor power | kW | 30 | 37 | ||
| Max. quill torque | Nm | ||||
| Max. spindle torque | Nm | 2865 | 3532 | ||
| Max. spindle feeding force | N | 20000 | 35000 | ||
| Ram size | mm | ||||
| TRAVEL | Max. Column travel(X) | mm | 3000 (or more) | 3000 (or more) | |
| Max. headstock travel (Y) | mm | 2000 (optional 1600, 2500) | 2000(optional 1600, 2500) | ||
| FEEDING | Cutting feed | X axis | mm/min | 1~4500 | 1~4500 |
| Y axis | mm/min | 1~4500 | 1~4500 | ||
| Z,W axis | mm/min | 1~2000 | 1~2000 | ||
| Feed rate | X axis | mm/min | 8000 | 8000 | |
| Y axis | mm/min | 9000 | 9000 | ||
| Z,W axis | mm/min | 3000 | 3000 | ||
| POSITIONING ACCURACY | X axis | mm | ±0.020/1000 | ±0.020/1000 | |
| Y axis | mm | ±0.020/1000 | ±0.020/1000 | ||
| Z,W axis | mm | ±0.02 | ±0.02 | ||
| REPEATABILITY | X,Y,Z,W axis | mm | ±0.01 | ±0.01 | |
| TOTAL POWER | -- | kVA | ABOUT 100 | ABOUT 100 | |
| SIZE | L*W*H | mm | 6400*4000*4815 | 9000*8600*5200 | |
| WEIGHT | -- | kg | 32000 | 42000 | |
| MODEL | UNIT | TOM-TK6913 | TOM-TK6916 | TOM-TK6920 | ||
| HEADSTOCK | Spindle dimater | mm | 130 | 160 | 200 | |
| Quill diameter | mm | 221.44 | 260 | 300 | ||
| Taper(7:24) | -- | ISO50 | ISO50 | ISO60 | ||
| Too shank | -- | JT50/ OPTIONAL BT50 | JT50/ OPTIONAL BT50 | JT60/ OPTIONAL BT60 | ||
| Pull stud | -- | LD—50D/ OPTIONAL P50T-I | LD—50D/ OPTIONAL P50T-I | LD—60D/ OPTIONAL P60T-I | ||
| Spindle speed | rpm | 2~1500 | 2~1000 | 2~1250 | ||
| Main motor power | kW | 37 | 55 | 60 | ||
| Max. quill torque | Nm | 2500 | ||||
| Max. spindle torque | Nm | 2500 | 5000 | 6000 | ||
| Max. spindle feeding force | N | 25000 | 50000 | 55000 | ||
| Ram size | mm | 420×480 | 480×580 | 480×580 | ||
| TRAVEL | Max. Column travel(X) | mm | 6000 (or more) | 8000 (or more) | 10000 (or more) | |
| Max. headstock travel (Y) | mm | 2000(optional 4000, 5000) | 3000(optional 4000, 5000) | 4000(optional 5000, 6000) | ||
| Max. Ram travel (Z) | mm | 800 | 1100 | 1200 | ||
| Max. Spindle travel (W) | mm | 800 | 900 | 1200 | ||
| FEEDING | Cutting feed | X axis | mm/min | 1~3000 | 2~5000 | 2~6000 |
| Y axis | mm/min | 1~3000 | 2~5000 | 2~6000 | ||
| Z,W axis | mm/min | 1~2000 | 2~3000 | 2~4000 | ||
| Feed rate | X axis | mm/min | 8000 | 5000 | 8000 | |
| Y axis | mm/min | 8000 | 5000 | 6000 | ||
| Z,W axis | mm/min | 6000 | 3000 | 4000 | ||
| POSITIONING ACCURACY | X axis | mm | ±0.020/1000 | ±0.020/1000 | ±0.025/1000 | |
| Y axis | mm | ±0.020/1000 | ±0.020/1000 | ±0.025/1000 | ||
| Z,W axis | mm | ±0.02 | ±0.02 | ±0.025 | ||
| REPEATABILITY | X,Y,Z,W axis | mm | ±0.01 | ±0.01 | ±0.01 | |
| TOTAL POWER | -- | kVA | ABOUT 120 | 155 | 155 | |
| SIZE | L*W*H | mm | 10720*4000*4970 | 14560*7155*7100 | 16560*7455*8400 | |
| WEIGHT | -- | kg | 54000 | 110000 | 126000 | |
MACHINE PHOTOS:
ACCESSORIES SUPPLIERS:
PACKING:
EXHIBITION:
OUR FACTORY:
Company information:
Company Information
HHT Machine is part of a machine tool industry chain; called a 4S alliance.This alliance consists of enterprises focusing on specialized, characteristic and refined machine tools, colleges and research institutes. Those Enterprises include mines, ironworks, casting, machining, functional components supply, equipment and complete machine assembly and sales, after-sales service, research and development and design. HUAIAN HAOYANG MACHINE CO., LTD-HHT MACHINE is the overseas sales link of the alliance,HHT MACHINE mainly includes CNC lathes, CNC machining centers, CNC planer milling machines, CNC planer boring machines and turret milling machines.
In order to make you know more about us, here ntruduce more details to you:
1.After-sales service:
a. Free installation and debugging
b. Free operator training
c. Free maintenance within 1 year
d. Long warranty and technology support
2. Delivery Date: it will be confirmed when you make the order.
3. Payment Terms:
3.1. 30% Deposit by TT before production and 70% payment by TT before shipment;
3.2. 30% deposit by TT before production and 70% L/C at sight before shipment;
3.3. 100% L/C at sight.
4. Our advantages:
4.1. We always offer what you want. We never recommend anything that you don’t need.
4.2. We have the best price for the similar machines of the same quality.
4.3. We always offer excellent after-sale-service. We are not the supplier who expect only once business with a customer, we always try to do the best for long-term business relationship.
If you are interesting in our products, please contact me Linda zuo, my telephone no. is +86 13861572987
