Specifications
longspan shelving ;mediun duty racking;storage rackThe height of each layer can be adjusted by pitch 50mm freely
Medium Duty Racking
Structure: Cut-in composite step beam on which steel or wooden panels are assembled; the height of each layer is easily to be adjusted by 50mm, the capacity of each level is up to 1000kg; the racking can be customized based on clients’ requirements, compared with the NM1A,NM1B, it is more suitable for storing metal components and widely used in the manufacturing industry.
Specification: Sectional Size of Upright (mm): 60*50
Available beam size(mm): P60*40,P80*50,P110*50
1) Dimentions:D300-1200
W1000-30002) Surface treatment: Powder or galvanised surface coating.
3) Height:The height of each layer can be adjusted by pitch 50mm freely
H1200-6000
4) OEM: Produce according to customer's requirement.
5) Loading capacity: 300kg/level-1000kg/level. 5400kg/bay
6) Surface treatment: Powder coating finishing
Racking process
- Pre dispose
Black racking—degreases (remove oil in the surface, use Germany Henkel removes the rust and degreases) – water washing – Acid washing – Water washing – neutralization—Water washing – adjustment—phosphoric (neutralization hydronium phosphoric and prevent rust)—water washing—water washing
2. Automatic Powder coating
Hang the part—pre dry—automatic coating—high temperature solidity – packaging
The powder coating is working on our advanced importing automatic powder coating line9USA NORDSON), epoxy resinic static coating, the surface rigidity is 2H, the attach strength is more than 2 level of GB92865-88 Standard, bear causticity (salt fog test) GB1771-91>500 hours, the surface coating is satisfy GB9286 standard.
| Others: | ||
| Design: | professional design for your requirment:include choose the correct type for you,CAD drawing | |
| Price | direct Manufacture price,according to your quantity,payment | |
| Package | standard export package | |
| Payment | 30%prepaid T/T,L/C at sight FOB,CNF,CIF |
|
| Shippment | FOB NANJING,FOB SHANGHAI | |
| CNF/CIF destination port | ||
| Quick Delivery. | Within 15-20 days for ordinary order quantity. Big production capacity allow us in a position to make quick delivery. | |
| Certification | CE:if you need,can make for you others:ISO9001,ISO14001,ISO10012 |
|
| Important information for quick quotation: | ||
| 1. Racking's DxWxH | ||
| 2. Loading capacity per level | ||
| 3. Quantity of levels | ||
Any further questions you can contact me: skype:hj84082383 or trade manager.
