PRODUCT INFOMRATION
1.It is mainly used for the storage of long stuff such as rolled section steel, steel tube, plates, wire lines and so on.
2.Upright shaft is usually made of H type steel or cold rolling steel or frame, square tube, cold rolling steel or H type steel are used to make arms.
3.Cantilevers are assembled to upright shafts by composite type or bolts&nuts which is also for the fixation between base and uprights.
4. Level height is adjustable. Loading and unloading of goods can be done manually or by forklifts.
5.The height of cantilever racking is usually lower than 2500mm (the height up to 6000mm by using forklifts for loading); length of arm is shorter than 1200mm, and loading capacity is no more than 1200kg per arm.
6.Cantilever racking is mainly used in the Mechanical Manufacturing Industry and markets for building materials.
Technical characteristics Cantilever racking
- The column and foot are welded or bolted together.
- The cantilever racks can be used single or double sided.
- Column heights of up to 5 meter, perforated every 100mm.
- The Cantilever racking is suitable for forklift and crane handling.
- Ground guidance can be provided as an option.
- The beams are bolted and adjustable per 100mm, corresponding with the sizes of the stored goods.
- Arm lengths of our Cantilever racking range from 600 to 1500mm.
