AS/RS system is composed of one or more aisles, each having a stacker crane to retrieve from and store product in the racks on either side of the aisle.
1. Dramatic improvements in operator efficiency and storage capacity
2. Reduction of work-in-progress inventory
3. Improvements in quality and Just-in-Time performance
4. Provides make-to-order capability in addition to make-to-inventory production
5. Inventory control and instantaneous reporting functionality
6. The use of a robotic crane allows racks to be built several stories high over almost any length, providing more storage density than almost any other storage solution.
AS/RS System:
1. Racking
Structural feature: AS/RS System are usually equipped with pallet racking and drive-in racking, both of which are composite structure. Steel panels and wooden panels are available for loading with good capacity. Conveyors will do the loading and unloading job under the instruction from the central computer. AS/RS System is mainly used in the food, tobacco, electronic, mechanical and armament industry.
Model: NH heavy duty pallet racking
Specification:
2. Stacker
Structural feature: Double upright structure, steady and reliable, vector frequency conversion drive and encoder position control, mechanical and electronic safety devices to ensure safe using of the system; all the way tracing technology by information transferring; electric components are imported from abroad; touching screen interface for easy operation; making manual, semiautomatic, automatic andlinkage control come true; used in many situations by combining with other logistics equipment.
Model |
Loading Capacity (kg) |
Height |
Walking Speed |
Remark |
DPL-0.1T |
100 |
5-30m |
160m/min |
Customized based on client’s requirements |
DPL-0.5T |
500 |
160m/min |
||
DPL-1T |
1000 |
160m/min |
||
DPL-2T |
2000 |
120m/min |
||
DPL-3T |
3000 |
100m/min |
3 .Conveying system
Structural feature: Conveying system is usually equipped in the front or back of warehouse for conveying goods here and there, bridging the procedures done by forklifts and stackers by using rolling conveyor or chain conveyor and combining with lifts, rotating devices and other equipments.
Specification:
4. Controlling system
Structural feature: Communicating with WMS and ECS through OPC agreement, PROFIBUS bus network, set up by SIEMENS S7-300 controller can operate all conveyors offline, doing conveying of goods automatically.
Please refer to the attached drawing for details of conveying system
5. WMS System
Hardwares of WMS System: star network structure, network sever, RF server, computers for management and monitor, RF base station and RF terminal for in/out warehouse of goods.
Softwares of WMS System:
Operating system: WINDOW 2000X SEVER
Data-base: MS SQL SEVER 2000X
Warehouse management software: WMS
Equipment controlling software: ECS
Bar code management software: RFS
We are professional manufacturer of all types of Racking system since 1997, supply you with quality products at competitive prices. We would like to be your reliable supplier and trusted friends.
Thank you for your attention! If you have any concern or questions, kindly contact us at below Chat Window or add my Skype(sherry91yao), we all help you out at the earliest.
AS/RS System Showcase:
Workshop and Factory:
