Help CenterHard Rubber Swivel Dual Wheel
Related Products
-
2013 European Type Bolt Hole Swivel Twin Wheel CasterUS$ 0.2 - 10MOQ: 500 Pieces -
TPR Dual Wheel Swivel CastorsUS$ 0.2 - 10MOQ: 500 Pieces
-
Top Plate Plastic Wheel European Type Twin Wheel Swivel CasterUS$ 0.2 - 10MOQ: 500 Pieces
-
European Type TPR Wheel Bolt Hole Double Brake Twin Wheel CasterUS$ 0.2 - 10MOQ: 500 Pieces
-
European Type TPR Wheel Bolt Hole Twin Wheel CasterUS$ 0.2 - 10MOQ: 500 Pieces
| Technical Data | |
| Wheel diameter | 50mm |
| Width of Tread | 20mm |
| Size of Plate | 60x60mm |
| Plate hole centres | 46x46mm |
| Plate hole | 12x6.5mm |
| Offset | 27mm |
| Overall height | 71.5mm |
| Temperature | -10 -50 °C |
| Load capacity | 70kg |
| Hardness of tread | 100 Shore A |
Housing:
Made of pressed steel,zinc plated,
double ballrace swivel head,dustproof seal
Wheel:
Materials: Hard rubber wheel
Hardness: 100 Shore A
Temperature range: -10°C~50°C
Twin Wheel Casters are highly used across many markets, and are very popular among store fixtures, seating, medical equipment, and furniture.
This Series casters are available in twin-wheel swivel and fixed designs that provide a narrower footprint than other wheels in the industry and easier turning due to the differential action of the wheels.
Also design for business machines,displays, appliances and other lowheight applications.
They are supplied with 2" wheels and have a load capacity of 440 lbs. and are fittedwith a rectangular top plate.
From the die-cast decorative Pacer twin wheel, to the heavy duty ever quiet Softech- you are
bound to find a Twin Wheel Caster that meets your mobility requirements.
Rounya's swivel casters rotate 360 degrees which makes turning the mating equipment possible.
Rounya's rigid casters are typically used in combination with swivel casters since rigids only allow the caster to roll in a straight line.
Rounya's bolt hole fitting casters can be mounted with threaded or friction ring stems.
Rounya's bolt hole fitting brake casters can be mounted with threaded or friction ring stems.
Wheel Materials:
* Nylon caster is the hardest durometer wheel in our line. It has excellent wear, impact resistance, load capacity and can be used in outdoor environments.
* Polyurethane caster is the most versatile caster in our group since it can be used in most hard and soft wheel applications.
* Black Rubber caster is one of the most widely used casters for indoor environments due to it's quieter wheel operation.
* Elastic Rubber is our softest wheel available. This caster is great for lighter loads where quiet operation and floor protection are a must.
* Plastic is our only caster availabe with a low profile housing that minimizes the equipments overall height compared to standard height casters. This caster is great for lighter loads that require excellent wear and abrasion resistance.
Wheels are available in sizes from 2" to 16" and in materials matched to your temperature & chemical operating environment.
Various caster mounting configurations are available for designing, building, repairing, or refurbishing equipment.
We offer a wide variety of top or side locking brake types
- Top Locking
- Side Locking:Plastic/Nylon/Steel Pedal
- Double Lock
- Universal
- Position Swivel Lock/Directional Lock
In addition, you can choose from multiple finishes including:
- Chrome
- Black Ionic
- Yellow Chromate
- Stainless Steel
- Zinc
- Other finishes to match your needs
We can provide various industrial caster bearings:
- Delrin Bearings
-
Roller Bearings
- Nylon
- Steel
- Flange Bearings
- Plain Bearings
- Ball Bearings
- Nylon Bearings
- Steel Bearings
For more information, contact The Rounya Caster Company, No.A1-2,1st Industrial Zone,529932
Phone:+86 (0) 13411317724: +86-662-2288280 Fax: +86-662-2288290
Please address reader service inquiries at the above address to:
Fenny chan, Sales Manager, Rounya Caster Company
E-mail inquiries to: info(at)
