Lcd 3.2" 240x320 Resolution TFT Lcd Screen High Brightness 500cd/m2 With Touch Panel 40pin Connector

Lcd 3.2" 240x320 Resolution TFT Lcd Screen High Brightness 500cd/m2 With Touch Panel 40pin Connector thumbnail-1
Lcd 3.2" 240x320 Resolution TFT Lcd Screen High Brightness 500cd/m2 With Touch Panel 40pin Connector photo-1
US$ 6 - 8 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HaoRan
Model Number:
HT032K4QV40T
Contact Supplier Request Quote Chat Now
Shenzhen Haoran Display Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HaoRan
Model Number HT032K4QV40T
Type TFT

Specifications

3.2 inch TFT lcd Module,High quality

 Specifications:

Main Parameters:

Item HaoRan 3.2inch TFT lcd screen
Model name HT032K4QV40T
Display Mode Normally White,Transmissive
Resolution 240 x3 RGB x 320
Technology Type a-Si TFT active matrix
Pixel Pitch (mm) 0.2025(H) x 0.2025(V)
Pixel Configuration R.G.B. Vertical Stripe
Outline Dimension 55.04(W)x77.7(H)x3.5(D)
Active Area(mm) 48.6(W)x64.8(H) mm
Interface MCU 8080 8bit/16bit
Viewing Direction 12 O'Clock
Surface treatment: Anti-Glare
Touch Panel Optional
LED Numbers 6 pcs
Color Depth 16.7M color
Operating   Temperature -20~70°C
Storage Temperature -30~+80°C
 Brightness  300cd/m2



lcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connector





Product Range



♦  Monochromic LCDs/LCD Modules

◊ VA,TN,HTN,STN,FSTN,DFSTN LCD Panels and its accessory
◊ Graphic,Character,Alphanumeric and In cell touch modules
◊ COB,COG,TAB Package
♦  Color TFT LCD Modules
◊ 1.67inch to 10.4inch color TFT LCD Display
 ♦  Touch Screen
◊ Capacitive touch screen
◊ Resistive touch screen
♦  For more details pls visit our website /





Main Application

Telecommunication Devices Telephone,interphone,watch,tablet PC,radio,etc
Consumer Products Camera,DVD player,toy, Cell Phone,game player,etc
Technical Equipment Elevator controller,Industrial machine,etc
Office Automation Printer,scanner,attendance machine,fax machine,etc
Home Appliances Air-condition display,refrigerator,electric cooker,video doorbell,etc
Automobile GPS,video player,speedometer,audio broadcast,etc
IT Products Camera,handheld digital video,projector,media play,tablet PC,etc
Medical Equipment Ultrasound machine,therapeutic equipment Blood pressure meter,etc

lcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connector



 lcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connectorlcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connectorlcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connector



lcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connector



Complying with RoHS.



Warranty: All parts are tested working well before shipping out .



lcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connectorlcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connectorlcd 3.2" 240x320 resolution TFT lcd screen High brightness 500cd/m2 with touch panel 40pin connector

Part Of  TFT Products List :
Model Display Size Display Type Outline Active Area Viewing ANGLE Driver IC Interface Tuch panel Note
HT023A 2.3 320*240 50.8*45.8*3.3 46.75*35.06 12 ILI9342 8080 Y 34P
HT024D 2.4 240*320 42.72*60.26*2.3 36.72*48.96 12 ILI9341 8080 N 36P
HT028C 2.8 240*320 50.0*69.2*3.55 43.2*57.6 12 ILI9341 8080 Y 37P
HT030K1 3.0 240*400 45.04*77.0*3.45 38.88*64.8 12 ILI9327 8080 Y 40P
HT032C 3.2 240*320 55.04*77.7*3.6 48.6*64.8 12 ILI9341 8080 Y 37P
HT035C 3.5 320*480 54.58*84.71*2.0 48.96*73.44 MVA ILI9488 8080 N 37P
HT035G 3.5 320*240 76.9*63.8*4.5 70.08*52.56 6 NT39016D RGB Y 54P
HT038A 3.8 320*480 58.1*90.25*3.3 42.8*79.2 12 ILI9488 8080 Y 38P
HT040A 4.0 320*480 60.88*94.57*2.3 55.68*83.52 12 ILI9488 8080 N 39P
HT043B 4.3 480*272 105.5*67.2*3.95 95.04*53.86 6 OTA5180 RGB Y 40P/10 LED
HT043C 4.3 480*272 105.5*67.2*3.95 95.04*53.86 6 OTA5180 RGB Y 40P/7 LED
HT043K1 4.3 480*272 105.5*67.2*3.95 95.04*53.86 6 SSD1963 8080 Y 30P
HT043K2 4.3 480*272 105.5*67.2*3.95 95.04*53.86 6 SSD1963 8080 Y 30P/with TP Controller
HT050A 5.0 800*480 120.8*75.85*4.6 108.0*64.8 6 ILI6126C RGB Y 40P
HT050B 5.0 480*272 120.8*75.85*4.6 110.88*62.832 6 ILI6480G RGB Y 40P
HT050K1 5.0 800*480 120.8*75.85*4.6 108.0*64.8 6 SSD1963 8080 Y 30P
HT050K2 5.0 480*272 120.8*75.85*4.6 110.88*62.832 6 SSD1963 8080 Y 30P
HT070D 7.0 800*480 164.9*100.0*5.7 154.08*85.92 6 ILI6126C RGB Y 50P
