lcd graphics tablet 5.7inch 320240 dot matrix Monochrome lcd module With RA8835 Controller LCD Display
USD $30 - $50
/ Piece
1 Piece(Min.Order)
- 100000000 Piece / Pieces per Month
- SHENZHEN
- T/T
You May Like
-
negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
-
digital fire alarm installation module display, HTN segment display with blue led lcd panel
-
negative autoreclose circuit-breaker lcd display, segment module with blue led
-
charger negative character lcd display,white led ,battery segment small flexible display
-
character small charger lcd display ,custom battery display ,white led
-
segment positive temperature time clock lcd display,blue TN white backlight
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | HaoRan | Model Number: | HG320240A |
| Type: | Graphic |
Product Description
Specifications
5.7"monochrome lcd graphics tablet1.320x240 dot matrix
2.RA8835 Controller
3.8bit 8080 parallel CPU interface
Specifications:
| Main Parameters: | |
| Item | HaoRan 320x240 5.7inch STN lcd module |
| Model name | HG320240ADPSW |
| Display Mode | Normally White,Transmissive |
| Resolution | 320x240 |
| Technology Type | FSTN |
| Pixel Pitch (mm) | 0.33(H) x 0.33(V) |
| Pixel Configuration | FSTN monochrome |
| Outline Dimension | 167.0(W)x109.0(H)x12.0(D) |
| Active Area(mm) | 121.0(W)x93.0(H) mm |
| Interface | Mcu 8080 8bit |
| Viewing Direction | 6 O'clock |
| Surface treatment: | Anti-Glare |
| Touch Panel | Optional |
| LED Numbers | 12 pcs |
| Color Depth | Monochrome |
| Operating Temperature | -20~70°C |
| Storage Temperature | -30~+80°C |
| Brightness | 300cd/m2 |
lcd
| Product Range |
|
♦ Monochromic LCDs/LCD Modules |
| ◊ VA,TN,HTN,STN,FSTN,DFSTN LCD Panels and its accessory |
| ◊ Graphic,Character,Alphanumeric and In cell touch modules |
| ◊ COB,COG,TAB Package |
| ♦ Color TFT LCD Modules |
| ◊ 1.67inch to 10.4inch color TFT LCD Display |
| ♦ Touch Screen |
| ◊ Capacitive touch screen |
| ◊ Resistive touch screen |
| ♦ For more details pls visit our website / |
| Main Application | |
| Telecommunication Devices | Telephone,interphone,watch,tablet PC,radio,etc |
| Consumer Products | Camera,DVD player,toy, Cell Phone,game player,etc |
| Technical Equipment | Elevator controller,Industrial machine,etc |
| Office Automation | Printer,scanner,attendance machine,fax machine,etc |
| Home Appliances | Air-condition display,refrigerator,electric cooker,video doorbell,etc |
| Automobile | GPS,video player,speedometer,audio broadcast,etc |
| IT Products | Camera,handheld digital video,projector,media play,tablet PC,etc |
| Medical Equipment | Ultrasound machine,therapeutic equipment Blood pressure meter,etc |
| |
| Graphic: | ||||||||
| Model | Dot matrix | Outline size | Viewing Area | Dot size | Dot pitch | Backlight | Controller | Note |
| HG12864A | 128*64 | 113*65*13.5 | 73.5*39 | 0.48*0.48 | 0.04 | LED/EL | KS0108 | COB |
| HG12864B | 128*64 | 54*50*9.5 | 43.5*29 | 0.40*0.30 | 0.04 | LED/EL | KS0108 | COB |
| HG12864C | 128*64 | 93*70*12 | 72*40 | 0.48*0.48 | 0.04 | LED/EL | KS0108 | COB |
| HG12864D | 128*64 | 78*70*12 | 62*44 | 0.55*0.39 | 0.05 | LED/EL | KS0108 | COB |
| HG12864E | 128*64 | 93*70*12 | 70.7*38.8 | 0.48*0.48 | 0.04 | LED/EL | KS0108 | COB |
| HG19264A | 192*64 | 100*60*12 | 84*31 | 0.36*0.36 | 0.05 | LED/EL | KS0108 | COB |
| HG19264B | 192*64 | 122*62*13 | 104*39 | 0.46*0.46 | 0.04 | LED/EL | KS0108 | COB |
| HG19264C | 192*64 | 130*65*13 | 104*39 | 0.46*0.46 | 0.04 | LED/EL | KS0108 | COB |
| HG240128A | 240*128 | 144*104*13.5 | 114*64 | 0.40*0.40 | 0.05 | LED/EL | T6963C | 22P |
| HG240128B | 240*128 | 144*104*13.5 | 114*64 | 0.40*0.40 | 0.05 | LED/EL | T6963C | SMT/COB |
| HG320240A | 320*240 | 167*109*12 | 122*92 | 0.33*0.33 | 0.03 | CCFL/LED | RA8835 | SMT,5.7" |
| HG320240B | 320*240 | 139*120*13.2 | 103*79 | 0.27*0.27 | 0.03 | CCFL/LED | RA8835/N | SMT,5.1" |
