Specifications
Changeable stitch:in the same line can realize multiple density,it meets special fabric's structural requirements.
PRODUCT FEATURES:
1,Specialcam design let the carriage knitting changed the original magnetic control into motor control.
2,Small carriage,can return fast,improved work efficiency.
3,Design system,made by hengqiang new 16 yarn carrier software,with high compatibility and portable
operation.
4,Needle bed adopts the milling flute method,structure with special processing technology,it can complete
more complex patterns,achieved multi-function of single system needle bed.
MACHINE SIZE
| LONG (MM) | 2700 |
| WIDE (MM) | 930 |
| HIGH (MM) | 1800 |
TECHNOLOGY PARAMETERS
GAUGE |
5G,6G,7G,8G,9G,10G,12G,13G,14G,15G |
KNITTING SYSTEM |
SINGLE SYSTEM SINGLE CARRIAGE |
KNITTING WIDTH |
60"(INCH) |
KNITTING SPEED |
MAX.1.2M/SEC |
KNITTING FUNCTION |
TRANFER,TUCK,MISS,JACQUARD,INTARSIA,HIDE OR APPARENT SHAPING. |
STITCH DENSITY |
STITCH SYSTEM CONTROLLED BY STEPPING MOTOR,32 SECTION STITCH SELECTABLE,ADJUSTABLE SCOPE SUPPORTED BY SUBDIVISION TECHNOLOGY:0-650. |
RACKING |
CONTROLLED BY AC SERVO MOTOR,RACKING WITHIN 2 INCHES AND WITH FINE ADJUSTIING FUNCTION. |
DRIVE SYSTEM |
SYNCHRONOUS BELT DRIVE,AC SERVO SYSTEM. |
NEEDLE SELECTION |
CONTROLLED BY COMPUTER,ELECTRIC MAGNET NEEDLE CHOOSE SYSTEM WITH HIGH EFFICIENCY. |
YARN CARRIER |
1x8YARN CARRIERS ON EACH SIDE OF 4 GUIDE RAILS,SHIFTABLE ON ANY NEEDLE POSITION. |
TAKE DOWN ROLLER |
PROGRAMMED INSTRUCTION CONTROLLED BY STEPPING MOTOR,32 SECTION LEVELS SELECTION ADJUSTABLE AREA:0-100. |
PROTECTION SYSTEM |
THE MACHINE WILL AUTOMATICALLY ALARM IF YARN BREAKING,FLOAT YARN,REWIND,END OF KNITTING,FAIL OF RACKING,NEEDLE BREAKAGE AND ERROR PROGRAMMING OCCUR ECT. |
CONTROL SYSTEM |
1,ADOPT LCD SCREEN,INPUT DEVICE:USB,SYSTEM MEMORY 256MB,A GREAT AMOUNT OF DESIGN FILES CAN BE STORED. 2,MONITORING MENU,EACH KIND OF ORERATING PARAMETER,CAN BE SHOWN,AND THEY CAN BE ADJUSTED AT ANY TIME WHEN THE MACHINE IS RUNNING. 3,DESIGN SYSTEM IS VISUAL AND EASY TO UNDERSTAND AND UPGRAD. 4,MULTI LANGUAGE VERSION,THERE ARE CHINESE,ENGLISH ETC. |
POWER |
220V,SINGLE-PHASE,HAVE MEMORIZING FUNCTION AT THE POWER-OFF MOMENT. |
THIS SERIES CONTAINS MODELS
MODEL |
EXPLAIN |
| GSJX-1-44 | SINGLE SLOT,44",SINGLE CARRIAGE |
| GSJX-1-52 | SINGLE SLOT,52",SINGLE CARRIAGE |
| GSJX-1-60 | SINGLE SLOT,60",SINGLE CARRIAGE |
| GSJX-1-80 | SINGLE SLOT,80",SINGLE CARRIAGE |
| GSJX-(1+1)-80 | 1+1 SYSTEM,80",DOUBLE CARRIAGE |
| GSJX-1-44C | SINGLE SLOT,44",SINGLE CARRIAGE,COMB |
| GSJX-1-52C | SINGLE SLOT,52",SINGLE CARRIAGE,COMB |
| GSJX-1-60C | SINGLE SLOT,60",SINGLE CARRIAGE,COMB |
