DJF Mineral Detector and Detection

DJF Mineral Detector and Detection thumbnail-1
DJF Mineral Detector and Detection thumbnail-2
DJF Mineral Detector and Detection photo-1
DJF Mineral Detector and Detection photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
GOLD
Model Number:
DJF
Contact Supplier Request Quote Chat Now
Chongqing Huobo Surveying Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name GOLD
Model Number DJF

Main Applications and Features

  • High Power Direct Current IP Measuring System includes: receiver, time domain IP transmitter, rectification power, simulator and dummy load. The system is a high-tech product which integrated with geophysics, electronics, computer technology, information processing technology, aiming to hydro-geological, mineral geology, engineering geology, energy, geology, environmental geology applications.
  • For large areas of metal mining, non-metallic mineral resources, geological survey and detailed survey work, search for groundwater and other hydrological and engineering geological exploration.
  • The system transmitter has two synchronization mode (domestic initiation): delay synchronization after pulse and high-precision quartz clock synchronization, which allows high efficiency of field production, also convenient and flexible.


System Composition
One 5/10/15KW High Power Direct Current IP Transmitter
One 5/10/15KW High Power Rectifier Power Source
One or more DJS-8B Direct Current IP Receiver
Electrodes AB, Power Lines AB, Measuring Electrodes, and other related accessories



DJF-2 5/10/15kw Transmitter

  • Auto time travel, with regular current storage function to facilitate future resistance calculation
  • Micro-computer controlled, large-screen LED to display output voltage and current, touch panel.
  • Provide with RS-232 serial interface to facilitate the transferring of current data
  • High voltage, high current, with over-voltage and over-current protection and circuit-opening attention



specifications



  • Maximum Transmitting Power: 5 /10 /15KW
  • Maximum Power Supply Voltage: ± 1000 V
  • Maximum Power Supply Current: 5/10/15A
  • Power Supply Pulse Width: 1~60 sec.
  • Output Waveform: Bipolar waveform, Duty Cycle 1:1
  • Current Storage Time Interval: Programmable, Step Length: 1 minute
  • Data Storage: Can store current data not less than 8,000 groups (including data like year, month, date, hour, minute, etc. of measurement time), with power-failure protection
  • Large Screen Display: 160 × 128 Lattice Graphic LCD
  • Working Temperature: -10°C~ +50°C, 95%Rh
  • Storage Temperature-20°C~ +60°C
  • Volume: 476×309×247 mm
  • Weight: 12 kg



Packaging & Shipping



Package: Wooden Case or Plywood

Shipping: within 10 working days after receival of deposit



Our Services

     Engineers available for overseas service of the machinery



Company Information

  Established in 2009.Chongqing Gold Mechanical & Electrical Equipment Co,. Ltd is a high-tech enterprise specializing in R&D design, manufacture and sale of geological instruments, oil instruments and other precise instruments and equipments.
