Help CenterGround Prospecting Radar, Underground Metal Finding GPR System
Related Products
-
Digital Ground Prospecting Radar, GPR SystemUS$ 1 - 50,000MOQ: 1 Set -
Au,Ag and Other Precious Metal Jewelry AnalyzerUS$ 0.1 - 0.2MOQ: 1 Set
-
Precious Metal Jewelry Test XRF AnalyzerUS$ 0.1 - 0.2MOQ: 1 Set
-
XRF Gold,Silver and Other Jewelry Analysis InstrumentUS$ 0.1 - 0.2MOQ: 1 Set
-
Portable Deep Ultrasonic Well Depth FinderUS$ 1 - 50MOQ: 1 Set
Typical Application:
Utility location
Tunnel lining detection & advanced prediction
Road quality inspection
Mining, Geology, Hydrological survey
Rebar & Cable detection
Dam inspection
Life detection
Geotechnical engineering
Concrete inspection
Archeology
Main Featrures:
The integrated design of host and antenna
Easy to use, no field installation
High reliability wireless communication
Easy-to-use interface，one-click parameter setting, perfect or the field operation
Main Specification:
Center frequency: 100M 200M 400M 600M 1GHz 1.6GHz
Pulse repeated frequency: 50kHz~250kHz
Time range: 0-800ns
Number of samples: 512-8192 samples/scan, user selectable
Scan rate: 1-480 scan/sec
Operating modes: Point mode, survey wheel, free run
Display modes: Pseudo color，stacked waveform or grey-scale
Operating temperature: -10℃-+70℃
Battery: Li-Ion (12V 10AH)
Wireless Communication: 802.11b/g/n,>25 m
Wired communication: RJ45 100BT Ethernet
Packing Detailes:
The product will be packed by customized wooden case, detailed dimension and weight information will be provided after packing.
Any question please feel free to contact:
Gold Tao
Cell: +86 15922982462
Tell: +86 23 62794421
Fax: +86 23 62940030
Skype: goldgeo
Geophysical Multi-electrode 2D Underground Resistivity Survey System
Geophysical Distributed Multi-electrode 2D/3D Resistivity & IP Survey System
