Borewell Inspection Camera Downhole Underwater Inspection Camera System

Borewell Inspection Camera Downhole Underwater Inspection Camera System photo-1
Borewell Inspection Camera Downhole Underwater Inspection Camera System photo-2
Borewell Inspection Camera Downhole Underwater Inspection Camera System photo-3
Borewell Inspection Camera Downhole Underwater Inspection Camera System photo-4
Borewell Inspection Camera Downhole Underwater Inspection Camera System photo-5
US$ 5.00 - 5.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Gold
Model Number:
GYGD-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Chongqing, China
Brand Name Gold
Model Number GYGD-2
Product Description

Main application:

Stratum structure divide
Well wall stratum crack
Karst development discrimination
Distinguish fractured development zone
Determine the karst distribution position
Long time underground borehole monitoring

Main features:

Real time video, collect, record
Clearly image show on ground instrument
Vertical drilling hole, horizontal drilling hole, arbitrary drilling hole
Widely used in water well, oil field, coal field, engineering geology, dam, reservoir,
oceaneering.

No.
Configuration
Dimension
Specification
1
Camera probe
Diameter: 50/80mm
Length: 470mm
1. Camera lens are manufactured with high-quality resins.
2. High-quality steel body with solid structure, not easy to be damaged.
3. Maximum bearable pressure: 20Mpa (can reach the depth of 2000m under water)
4. 6-12 LED lamps are available
2
Camera
1. Sony inducer 1/3'' CCD
2. HD 850 TVL image definition
3. Waterproof
4. Panoramic/Electric rotating lens camera
3
Specialized cable
Length: 0-2000m (optional)
1. With steel wire
2. Max bearable tension: 260kg
4
Control unit
1. 220V/380V/12V optional voltage mode
2. Aeronautic aluminium case
5
Downhole pulley
Logging depth counter equiped
6
Logging winch
Manual & electric winch available
7
HD DVR
SD card
Detailed Images
Packing & Delivery

Packing inforamtion

Wooden case, specific dimension will be provided after packing.
