2016 HI TARGET GNSS H32 V30 SURVEYING GPS RTK HI TARGET photo-2
US$ 0.1 - 0.2 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Christmas Island
Brand Name:
Hi-Target
Model Number:
H32
Contact Supplier Request Quote Chat Now
Chongqing Huobo Surveying Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Christmas Island
Brand Name Hi-Target
Model Number H32

          GPS RTK Price China Made  RTK GNSS Cheap Sale  Survey instruments



2016 HI TARGET GNSS H32 V30 SURVEYING GPS RTK HI TARGET

MEASUREMENTS



• 120 Channels



• Proven NovAtel GNSS technology



• Multipath mitigating technology



• Auxiliary strobe signals, including a configurable output for time synchronization and mark inputs





GPS: L1, L2, L2C



GLONASS: L1, L2



Galileo: E1



GIOVE-A/GIOVE-B (test)



BDS/Compass



SBAS



QZSS







POSITIONING PERFORMANCE[i]







Static and Fast Static GNSS surveying



Horizontal: 2.5mm+0.5ppm RMS



Vertical: 5mm+0.5ppm RMS







Post Processing Kinematic



(PPK / Stop & Go) GNSS surveying



Horizontal: 1cm+1ppm RMS



Vertical: 2.5cm+1ppm RMS



Initialization time: typically 10 minutes for base while 5 minutes for rover



Initialization reliability: typically > 99.9%







Real-time Kinematic (RTK) surveying



Horizontal: 10mm+1ppm RMS



Vertical: 20mm+1ppm RMS



Initialization time: typically < 10 seconds



Initialization reliability: typically > 99.9%







Code Differential GNSS positioning



Horizontal: 25cm+1ppm RMS



Vertical: 50cm+1ppm RMS



SBAS: 0.60m Horizontal







HARDWARE







Physical



Dimensions (w x H): 16.5 cm x 10.5 cm (6.50 in x 4.13 in)



Weight: 1.75kg (3.86lb) with internal battery, internal radio, standard UHF antenna



Operating temperature: -45℃to +65℃ (-49℉ to +149℉)



Storage temperature: -55℃ to +85℃ (-67℉ to +185℉)



Humidity: 100%, considering



Water/dustproof: IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft).



Shock and Vibration: Designed to survive a 2m (6.56ft) natural fall onto concrete.



Display: 128×64 resolution, 1.54 inch OLED screen







Electrical



Power 6V to 28V DC external power input



Power consumption 2.5W



Automatic Switching between internal power and external power



Rechargeable, removable 7.4V, 4400mAh Lithium-Ion battery in internal battery compartment







Internal battery life



Static 13 - 15 hours



RTK Rover (UHF/GPRS) 10 - 12 hours



RTK Base 8 - 10 hours







I/O interface



1 x Bluetooth



1 x standard USB2.0 port



2 x RS232 serial port



2 x DC power input (8-pin & 5-pin)







COMMUNICATION AND DATA STORAGE







GPRS/GSM



Fully integrated, fully sealed internal GPRS/GSM



Network RTK (via CORS) range 20-50km







HI-TARGET internal UHF radio (standard)





Transmitting Power: 0.1W, 1W, 2W adjustable



Transmitting Speed: Up to 19.2Kbps



Working range: 3~5Km typical, 8~10km optimal







HI-TARGET External UHF radio (standard)



Frequency: 460 MHz with 116 channels



Transmitting Power: 5W, 10W, 20W, 30W adjustable



Transmitting Speed: Up to 19.2Kbps



Working Range: 8~10Km typical, 15~20km optimal







Support other external communication device



For example, external GSM modem.







Data storage



64MB internal memory







Data formats



(1Hz positioning output, up to 50 Hz - depends on installed option)



CMR: CMR+, CMR input and output



RTCM: RTCM 2.1, 2.3, 3.0, 3.1 input and output



RTCA: RTCA



Navigationoutputs: NMEA-0183, NovAtel ASCII and Binary logs
