hot sell Dual-Frequency Base and Rover Receiver Hi-Target V60 GPS RTK Survey Instrument

 hot sell Dual-Frequency Base and Rover Receiver Hi-Target V60  GPS RTK  Survey Instrument

Feartures:

Linux operation system
ARM 9G20 400MHz CPU, embedded Linux OS to support faster data transmission.

RINEX Storage
The static data can be saved directly in RINEX format. The V60 is fully compatible with other brands' receivers.

Quick Upgrade
Just copy the updated firmware to the V60, then restart to finish the upgrade in a few seconds.

Fully Automated Operation
The V60 is equipped with a smart speaker, which guides the user during operation. The guiding voice can be simply made in any language, even dialect! All its functionalities are designed to make survey jobs to be done conveniently, such as auto base setup by buttons, the rover can get fix solution once it is turned on. No need to spend time setting the parameters for every single operation.

Multi Constellation Tracking
220 channels. The V60 is fully compatible with GNSS constellations to track GLONASS, GALILEO, BOS, SBAS as well as GPS.

High Power Transceiver UHF Radio
The transceiver UHF radio enables the V60 working mode to be switchable between base and rover in the same receiver. 5 watts(Max.) HI-TARGET internal UHF radio or 2 watts(Max.) Pacific Crest internal UHF radio is optional to build in the V60. 5 watts transceiver UHF radio is an excellent choice for UHF RTK operation. On the other hand, 2 watts transceiver UHF radio is to be used to have the V60 work with other brand's receiver having UHF radios which support link protocols such as Transparent EOT/EOC/FST, Packet-switched, TrimTalk, TrimMark, Satel.

Seamlessly Operation in CORS System
With internal 3G modem, the V60 works perfectly with corrections from CORS networks in any version of CMR, RTCM without needing to interpret the message but reading seamlessly.

Long-life Battery
Powered by 5000mAh Li-Ion battery.
Static working time 13 - 15 hours
RTK Rover(UHF/GPRS/3G) working time 10 - 12 hours
RTK Base working time 8 - 10 hours

Rugged Design, IP67
The special latching technology on flexible flat cables ensures trouble-free operation under impact or vibration. The V60 withstands 3 meters natural fall onto concrete.

Field Controller and Software
There are optional field controllers and software in the V60 package. The controllers with OS Microsoft Windows Mobile 6.5 are fully compatible with the third party software such as Carlson SurvCE, MicroSurvey FieldGenius, DigiTerra Explorer, Esri ArcPad 10 etc. besides standard field&GIS software made by HI-TARGET. HI-TARGET controller with WiFi, Bluetooth, and GPRS/3G is completely wireless to connect to any devices, collect data and connect to server simultaneously and seamlessly. The software and controller, which can support Andriod OS are available from Hi-Target.

Post-processing Software
HI-TARGET Geomatics Office (HGO) software provides total GNSS solution with a complete suite of programs to support HI-TARGET GNSS receivers. Standard Rinex data and HI-TARGET raw data can be processed flexibly and easily

HI-Target  Post-processing Software——GNSS Receiver Manager V

                              Configuration List

Technical Specifiaction:

MEASUREMENTS
220 Channels
Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology
High precision multiple correlator for GNSS pseudo range measurements
Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response
Very low noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth
Signal-to-Noise ratios reported in dB-Hz
Proven Pacific Crest low elevation tracking technology
Satellite signals tracked simultaneously
GPS: Simultaneous L1C/A, L2C, L2E, L5
GLONASS: Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P
SBAS: Simultaneous L1 C/A, L5
Galileo: Simultaneous L1 BOC, E5A, E5B, E5AltBOC
BDS/Compass(optional): B1, B2
QZSS: L1 C/A, L1 SAIF, L2C, L5


POSITIONING PERFORMANCE
Static and Fast Static GNSS surveying
Horizontal: 2.5mm+0.5ppm RMS
Vertical: 5mm+0.5ppm RMS


Post Processing Kinematic
(PPK / Stop & Go) GNSS surveying
Horizontal: 1cm+1ppm RMS
Vertical: 2.5cm+1ppm RMS
Initialization time: typically 10 minutes for base while 5 minutes for rover
Initialization reliability: typically > 99.9%

RealtimeKinematic(RTK) surveying
Horizontal: 8mm+1ppm RMS
Vertical: 15mm+1ppm RMS
Initialization time: typically < 8 seconds
Initialization reliability: typically > 99.9%
Code Differential GNSS positioning
Horizontal: 25cm+1ppm RMS
Vertical: 50cm+1ppm RMS
SBAS[iv]: 0.50m Horizontal, 0.85m Vertical


HARDWARE
Physical
Dimensions (W x H): 19.50cm x 10.40cm(7.68 in x 4.09 in)
Weight: 1.3kg (2.86lb) with internal battery, internal radio, standard UHF antenna
Operating temperature: -45℃to +65℃ (-49℉ to +149℉)
Storage temperature: -55℃ to +85℃ (-67℉ to +185℉)
Humidity: 100%, considering
Water/dustproof: IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft).
Shock and Vibration: Designed to survive a 3m(9.84ft) natural fall onto concrete.

Electrical
Power 6V to 28V DC external power input
Power consumption 2.5W
Automatic Switching between internal power and external power
Rechargeable, removable 7.4V, 4400mAh Lithium-Ion battery in internal battery compartment

Internal battery life
Static 13 - 15 hours
RTK Rover (UHF/GPRS/3G) 10 - 12 hours
RTK Base 8 - 10 hours
I/O interface
1 x Bluetooth
1 x standard USB2.0 port
2 x RS232 serial port
2 x DC power input (8-pin & 5-pin)


COMMUNICATION AND DATA STORAGE
GPRS/GSM or 3G
Fully integrated, fully sealed internal GPRS/GSM or 3G
Network RTK (via CORS) range20-50km
HI-TARGET internal UHF radio (standard)
Frequency: 460 MHz with 116 channels
Transmitting Power: 0.1W, 1W, 2W adjustable
Transmitting Speed: Up to 19.2Kbps
Working Range: 3~5Km typical, 8~10km optimal
Pacific Crest ADL Foundation internal UHF radio
Frequency: 390~430 MHz or 430~470 MHz
Transmitting Power: 0.1W, 0.5W, 1W adjustable
Transmitting Speed: Up to 19.2Kbps
Support most of radio communication protocol
Working Range: 3~5km typical, 8~10km optimal
HI-TARGET External UHF radio (standard)
Frequency: 460 MHz with 116 channels
Transmitting Power: 5W, 10W, 20W, 30W adjustable
Transmitting Speed: Up to 19.2Kbps
Working Range: 8~10Km typical, 15~20km optimal

Pacific Crest ADL Vantage Pro External UHF radio
Frequency: 390~430 MHz or 430~470 MHz
Transmitting Power: 4W to 35W adjustable
Transmitting Speed: Up to 19.2Kbps
Support most of radio communication protocol
Working Range: 8~10Km typical, 15~20km optimal
Support other external communication device
For example, external GSM modem.
Data storage
64MB internal memory

Data formats
(1Hz positioning output, up to 50 Hz - depends on installed option)
CMR: sCMRx, CMR, CMR+input and output
RTCM: RTCM 2.1, 2.2, 2.3, 3.0, 3.1 input and output
Navigation outputs ASCII: NMEA-0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS Navigation outputs Binary: GSOF
1 Pulse Per Second Output
