Computerized Flat Knitting Machine Wool and Polyster Fabrics, With Sinker, Manufacturer
US$ 6,600 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, wool and polyster fabrics
Type:
Other, machine knitting wool and polyster fabrics
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Computerized Flating Kintting Machine Cotton and Others Blended Yarns, With Sinker, ManufacturerUS$ 6,000 - 8,000MOQ: 1 Set -
Computerized Machine Knitting Cotton/Acrylic Yarns With Sinker, ManufacturerUS$ 6,000 - 10,000MOQ: 1 Set
-
Computerized Machine Knitting SPUN, ManufacturerUS$ 4,800 - 7,500MOQ: 1 Set
-
Suzhou Computerized Machine Knitting FILAMENT, With Sinker, ManufacturerUS$ 6,600 - 8,000MOQ: 1 Set
-
Computerized Machine Knitting SPANDEX/ELASTIC/STREC/LYCRA, With Sinker, ManufacturerUS$ 6,600 - 8,000MOQ: 1 Set
Condition
New
Product Type
Other, wool and polyster fabrics
Type
Other, machine knitting wool and polyster fabrics
Production Capacity
100%
Place of Origin
Jiangsu, China
Brand Name
YIMA
Model Number
GSJX-1A-52
Power(W)
1KW
Knitting Style
Flat
Knitting Method
Single
Computerized
Yes
Weight
640kg
Dimension(L*W*H)
2670*1050*1830
After-sales Service Provided
Engineers available to service machinery overseas
computerized machine knitting wool and polyster fabrics, with sinker, manufacturer
1.GUOMAO computerized flat knitting machine product overview
| MODEL | GSJX-1A-52 |
| GAUGE | 14G |
| KNITTING SYSTEM | SINGLE SYSTEM |
| KNITTING WIDTH | 52INCH |
| KNITTING SPEED | 1.2m/s MAX.1.2M/SEC |
| KNITTING FUNCTION | TRANFER,TUCK,MISS,JACQUARD,INTARSIA,HIDE OR APPARENT SHAPING. |
| STITCH DENSITY | STITCH SYSTEM CONTROLLED BY STEPPING MOTOR,32 SECTION STITCH SELECTABLE,ADJUSTABLE SCOPE SUPPORTED BY SUBDIVISION TECHNOLOGY:0-650 |
| RACKING | CONTROLLED BY AC SERVO MOTOR,RACKING WITHIN 2 INCHES AND WITH FINE ADJUSTIING FUNCTION. |
| DRIVE SYSTEM | SYNCHRONOUS BELT DRIVE,AC SERVO SYSTEM |
| NEEDLE SELECTION | CONTROLLED BY COMPUTER,ELECTRIC MAGNET NEEDLE CHOOSE SYSTEM WITH HIGH EFFICIENCY. |
| COMB DEVICE | CHOOSE CLOSE U TYPE COMPOSE NEEDLE HOOK,THIS SPECIAL COMPOSE HOOK RELIABLE TO PICK UP YARN OR RELEASE. |
| SCISSOR AND CLAMP | INCLUDING 2 SCISSOR AND 4 CLAMPS ,WHICH INDIVIDUALLY CONTROLLED BY 6 MOTORS SEPARATELY,LOCATED THE BOTH OF NEEDLE BED SEPARATELY,FURTHER TO INCREASE THE WORK EFFICIENCY AND TO REDUCE YARN CONSUMPTION. |
| YARN CARRIER | 2x8YARN CARRIERS ON EACH SIDE OF 4 GUIDE RAILS,SHIFTABLE ON ANY NEEDLE POSITION |
| TAKE DOWN ROLLER | PROGRAMMED INSTRUCTION CONTROLLED BY STEPPING MOTOR,32 SECTION LEVELS SELECTION ADJUSTABLE AREA:0-100 |
| SINKER SYSTEM | ASSIST KNITTING,HAVE VARIOUS RESULTS OF SHAPING AND STOP. |
| PROTECTION SYSTEM | THE MACHINE WILL AUTOMATICALLY ALARM IF YARN BREAKING,FLOAT YARN,REWIND,END OF KNITTING,FAIL OF RACKING,NEEDLE BREAKAGE AND ERROR PROGRAMMING OCCUR ECT. |
| CONTROL SYSTEM | 1,ADOPT LCD SCREEN,INPUT DEVICE:USB,SYSTEM MEMORY 256MB,A GREAT AMOUNT OF DESIGN FILES CAN BE STORED.2,MONITORING MENU,EACH KIND OF OPERATING PARAMETER,CAN BE SHOWN,AND THEY CAN BE ADJUSTED AT ANY TIME WHEN THE MACHINE IS RUNNING.3,DESIGN SYSTEM IS VISUAL AND EASY TO UNDERSTAND AND UPGRAD.4,MULTI LANGUAGE VERSION,THERE ARE CHINESE,ENGLISH ETC. |
| POWER | 220V ,SINGLE-PHASE,HAVE MEMORIZING FUNCTION AT THE POWER-OFF MOMENT |
2.GUOMAO computerized flat knitting machine product dstails
3. GUOMAO computerized flat knitting machine customer factory
4.GUOMAO variety of sweaters can be produced by computerized flat knitting machine
5.GUOMAO computerized flat knitting machine cooperative partner
6. The auxiliary of GUOMAO computerized flat knitting machine
7. GUOMAO computerized flat knitting machine in the world
8.The certificate of GUOMAO computerized flat knitting machine
9.Welcome to GUOMAO knitting technology
