Land Surveying Instruments building surveying Total Survey Station
Application:
1. Mineral survey, exploration and excavation,Land surveying
2. Construction of railways, highways, Bridges, Building
3. Irrigation and water conservancy, urban planning and construction;
4. The battlefield preparation, harbor, fortress, airports and military engineering construction;
5. Precision positioning and installation in shipbuilding and aerospace industry ;
6. The three-dimensional coordinates, the location of measurement, pipeline orientation, cross section measurement of the stuctures;
7. The triangle control survey, topographic survey, cadastral and property measurement.
System Features
Compact, Lightweight Design
Rugged, compact design ensures the stability of every indicators of equipment and protect you from data loss on the harsh conditions.
Small size and light weight body make your work easily.
Quick Trigger Button
Measurement and record by pressing one quick trigger button, fast and convenient.
Stable Dual-axis Compensation
Simultaneous tilt compensation from horizontal and vertical angle makes sure the accurate measuring result, even when the body is rotating.
Vivid graphic electronic bubble display is available.
Upward Laser Pointing
Deviation from centre handle design makes upward laser pointing fast and easy, and no dead angle exists in upward measurement, which is significant for mining or tunneling application.
Powerful and Fast EDM Capability
600m Non-prism ranging.
Fine 0.8s, Track 0.3s in prism mode.
IP66 Dust and Water Protection
High standard IP66 performance provide protection from dust penetration and water driving.
Intelligent Calibration Software
The proprietary HI-TARGET Calibration software is accessible for real-time diagnosis to ensure trouble-free operation.
Software Compatibility
Compatible to the 3rd party data processing software, satisfying users’ requirements for different data format.
