Building and Packing materials aluminum foil bubble insulation

Specifications

Heat insulation made of two external pure aluminum foil layers covering a double core layer of polyethylene bubble air.

A2 Cat Tuong Double Material is composed of 2 layers of bubbles air made from polyethylene sandwiched between two layers of aluminum. The aluminum foils are heat reflective and the bubbles air are heat and sound insulation.

It keeps buildings warm in winter and cool in summer.

It is strong, light weight, clean and does not degrade over time.

It is easy and fast to install- usually save up to 50% labor time.

It prevents about 90% of heat radiation, decreases the temperature by 12-22C inside compared to the metal roof.

It can be installed under the roof, between the walls, under the ceiling and the floor.

It is environmental friendly, energy saving, fire retardant and has no odor or toxicity.

It replaces the glass wool or rock wool which after a few years degrade, became dusty and unhealthy.

It is largely used in industrial and civil construction, warehouse, livestock…in Vietnam, Thailand, China, Malaysia, Philippine, Indonesia, Australia, New Zeeland, United States…

      It can also be used in other application that needs shock protection such as bag in transport with container…

Thermal reflective insulation made of two external pure aluminum foil layers covering a single core layer of polyethylene bubble air film. (Product is manufactured by USA standard).



Structure: Aluminum foil/ Bubble Air Bag/ Bubble Air Bag/ Aluminum foil.





Property	Standard	Unit	Value
Sheet structure	Aluminum foil/ Bubble air /Bubble air / Aluminum foil
Roll Size		m x m	1.55 x 30
Sheet thickness		mm	6(± 0.5)
Roll weight		kg	24 (±0.3)
Yield strength		g/m2	320
Reflectivity	ASTM C1371	%	99.96
Emissivity	ASTM C1371	€	0.04
Classification of Surface Spread of Flame (Aluminum surface)	BS-476 .Part 7		Class 1
Elongation	ASTM D638	%	13.49
Tensile strength	ASTM D638	N/mm2	1.1
Tear strength	ASTM D1004	kN/m	16.24
Bursting strength	ISO 13938-2-99		120.8
Water absorption	ASTM E960	g/ft2 hr	0.19
Resistant to mold and bacteria			Yes
Toxicity			No
