Impregnated Diamond Core Drill Bit:
Brief introduction:
1.50 years professional manufacture
2. Certificate: TS16949 and ISO9001:2008
3. Export to: Africa, the Middle East, South America, Asia,
Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.
Size of Impregnated Diamond Core Drill Bit:
46~325mm with national and international standard
Main exportation: AQ,BQ,NQ,HQ,PQ
ITEM |
DIAMOND BIT |
REAMING SHELL |
|||||
"Q" Series Wireline |
Size |
Bit-set OD |
Bit-set ID |
||||
mm |
inch |
mm |
inch |
mm |
inch |
||
AQ |
47.6 |
1.88 |
26.97 |
1.06 |
48 |
1.89 |
|
BQ |
59.5 |
2.35 |
36.4 |
1.43 |
59.9 |
2.36 |
|
NQ |
75.3 |
2.97 |
47.6 |
1.88 |
75.7 |
2.98 |
|
HQ |
95.58 |
3.77 |
63.5 |
2.5 |
96 |
3.78 |
|
PQ |
122 |
4.8 |
84.96 |
3.35 |
122.6 |
4.83 |
|
Type of Impregnated Diamond Core Drill Bit: :
Impregnated diamond core drill bit; Natural surface-set diamond core drill bit;
Electroplated diamond core bit; Thin-wall diamond drill bit;
Concentric circular saw tooth diamond core dril bit; Casing shoe bit
Electroplated Diamond Hole Reamer, Sintered Diamond Hole Reamer
Use of Impregnated Diamond Core Drill Bit: :
Drill soft to hard rock, widely used in all kinds of drillings for prospecting, water and electricity building and construction industry of road, railway, bridge and building taking out core to examine stake,etc.
Structure of Impregnated Diamond Core Drill Bit: :
They are manufactured with very small, high quality synthetic diamonds mixed evenly through a metal matrix. FLYDISC core bits are manufactured to give optimum penetration rates and bit life, which is required to keep the cost of diamond drilling to a minimum.
We can manufacture according to the specific requirements of clients as drawing and samples.
]
