Help CenterJuice Making Machine /Juice Extractor/Small Fruit Extractor Machine
Related Products
-
Juice Making Machine /Juice Extractor/Screw Fruit JuicerUS$ 3,500 - 4,000MOQ: 1 Set -
Juice Making Machine /Juice Extractor/The Best JuicerUS$ 3,500 - 4,000MOQ: 1 Set
-
Juice Making Machine /Juice Extractor/Juicer TrituratingUS$ 3,500 - 4,000MOQ: 1 Set
-
Juice Making Machine /Juice Extractor/Multi JuicerUS$ 3,500 - 4,000MOQ: 1 Set
-
Juice Making Machine /Juice Extractor/Universal JuicerUS$ 3,500 - 4,000MOQ: 1 Set
Specifications
1,Stainless Steel2,High Output with low price
3,High Quality and high performance
4,Easy Operate
Model |
YH-1.5 |
Capacity |
1.5T/H |
Screw diameter |
175mm |
Screw speed |
400rpm |
Filter screen hole |
0.3mm |
Power |
4kw |
Dimension |
1560*450*1340mm |
Application:
For tomato, pineapple, carrot, apple ,aloe, cactus ,fruit and vegetable juice press.
By the propulsion of the screw axis extrusion, with juice, discharging function. The material of wet part made by high quality stainless steel
Description:
The Component of the machine included :front support ,hopper , spiral shaft, Filter net, juice holding device, back support , Out slag notch and so on . Screw shaft is supported on the bearing seat, the right end is supported on the wheel bearing seat, motor by a pair of belt wheel drives the screw shaft through operation.
Working way :
Screw shaft clockwise rotation along the direction of the Slag outlet, bottom diameter slowly become big but the Pitch narrows gradually ,when material pushed by the screw shaft ,Due to the spiral chamber narrows gradually, thus forming the material press. fruit and vegetable products join the hopper, the screw shaft propulsion and compression, by squeezing out the juice through a filter into the bottom of a juice holding device, and the slag by the axis of the screw and regulating head taper portion is formed between the annular gap discharge, pressure head can adjust the size of the gap, to adjust the slag resistance, can change the slag rate.
1.Fruits:pineapple .pear.apple
2.Berries fruit: mulberry fruit, grapes, oranges...
3.Vegetable:tomatoes, ginger, garlic, celery .carrot
Packaging Method: Wooden Case Package/Plywood Packing
Shipping Way: By Sea or By Air or By express:DHL UPS TNT FEDEX EMS (Select one way)
Packing Picture:
- One Year Guarantee for whole machine.
- 24 hours technical support by email.
- OEM is welcomed.
Our company integrates R&D, design, manufacture, sales and import & export of machinery into one. We always supply food machinery and security equipment with high quality & high performance, also with competitive price. Our company is located in the capital of China, Beijing City, which is the center of business and economy city.
In the concept of "Tolerance & Reputation, People-oriented & Innovation-driven, Technology & Service", we communicate, research and cooperate with universities, research institutes, engineering companies in various industries and system integrators in food machine industry and security industry.
With many cooperative factories, we can provide a wide range of products in order to cater for your special orders.
If you are interested in our company, please feel free to contact us. You will get superior service, and we produce machinery with high quality, high performance and the best prices.
