japanese classic cars for sale china manufacturer classic vantage car gasoline electric car for sale

12 units in a 40ft HQ container for mini moke car

Specifications

1, Classic style design
2, All oringinal parts except for engine.
3, RHD(right handle drive) or LHD system is available



At present, except for the pure foreign trade business, we are also searching for partners all over the developing regions to establish simple auto assembly plants in the locality, as such countries in Africa, the Middle East and Central America.This is quite a feasible and profitable project

indeed, because we have already set up assembling lines in Syria, Ghana and Costa Rica. In order to accomplish our ultimate goals that to develop, occupy and hold all the strategic significant marketing highlands of the third world countries.We now need to enhance our business coverage by adding a few more real foothold to form a entirely marketing system.

If you requested, we will send you more imformation about our project.





 Other Details about our mini moke

Engine	Item		Mini Moke
	Engine Type		in-line 4-cylinder, 4-stroke, EFI gasoline engine
	Max. Power		33.5 w/ 5000 rpm
	Max. Torque		72/3000-3500 (N.m/ rpm)
	Start		Electric Start
	Cooled system		Water Cooled
	Transmission Type		5+1
	Wheelbase		2100 mm (78 inches)
	Wheeltrack front/rear		1290mm(50.8 inches)/1290mm(50.8 inches)
	Curb Weight		858 kgs
Tyres	Front		145/70R12
	Rear		145/70R12
Brake System	Front		Disc
	Rear		Drum
Other Parameter	Steering system		Left hand drive / Right hand drive
	Body Type		Steel body
	Available Colour		Red, Green, Orange, Blue, Yellow, Pink, White, camouflage
	Country of Origin		Chongqing, China
Loading Volume	CBU (completely built up)		12 units/ 40HQ container
	CKD (completely knocked down)		24 units/ 40HQ container



English catalogue of electric power mini moke



Electric devices	Motor: 7.5kw,High-efficiency separately-excited winding motor
	Battery: 6*12V, 210A/H, traction battery with big capacity and deep circulation.
	Charger: Fully-automatic high-frequency pulse charger, input voltage AC 220V, 50Hz; output current 72V, 30A.
	600A INBOL controller
	Accelerator: induction accelerator 0-12V
	DC Module:72V-12V Direct current converter
Solar battery and charger	Solar battery and charger
Chassis	Frame type, high strength steel structure, both anti-rust treatments of electrophoretic paint and powder spraying
Cover panel	1. Steel boday; streamlined design; 2.Steel frame headlining with imported canvas
Brake system	Disc brakes (F), drume brakes (R ), plus vacuum booster pump
Front suspension system	Two A arms, spring + damper type (or MacPherson front suspension)
Rear suspension system	Towed semi-independent suspension
Steering system	rack-and-pinion steering and EPS system
Lighting system	Headlamp lamp assembly (headlamp, turn signal lamp), Tail lamp assembly (brake lamp, turn signal lamp, everlasting lamp)
Seats	1.Confirming to Human-Machine Engineering Principle, confortable seats; 2. Leather surface, waterproof, impermeable, corrosion resistance, resistance of yellowing, easy to clean;
Tire	165/70 R14 Mini cars' tire
2. Main technical data
Net Weight	≤ Car 450KG + batteries 250KG = 700KG
L * W * H	3110mm *1520mm *1600mm                                                                     Adding front and rear bumpers:3140mm *1520mm *1600mm
Wheel base	2200 mm
Front wheel track	1250mm
Rear wheel track	1270mm
Min. turning radius	2.5m
Load capacity	350kg(including driver, passenger, and cargos)
Full charge endurance	(IF install High-power li-ion battery power)   150 km
Min. ground clearance	200mm
Brake distance	≤4m (60km/h)
Climbing capacity	≤28%
Max. noise	≤ 50dB
Max forward speed	Client have two select: 60 km/h ; 80 km/h
Max. backward speed	8-10km/h
Driving gear	4 + 1 or 5 + 1
Body/headlining color	Black / Green / Camouflage hide-and-seek
Seats	4
Note: 1. The above parameters for reference only, and the specific technical indexes to factory state shall prevail. 2 this vehicle priority for ordering customers, satisfy customer individual requirements. Custom-made period for 45-60 days



  MINI MOKE Car of gasoline engine

Engine	Item		Mini Moke
	Engine Model		465Q-2D
	Engine Type		in-line 4-cylinder, 4-stroke, EFI gasoline engine Europe III and Europe IV standard
	Displacement		990 cc
	Max. Power		37.5 kw/ 5000 rpm
	Max. Torque		72/3000-3500 (N.m/ rpm)
	Start		Electric Start
	Cooled system		Water Cooled
	Transmission Type		5+1
Vehicle Parameter	Measurement(L*W*H)		3110mm *1520mm *1600mm
	Wheelbase		2100 mm (78 inches)
	Wheeltrack front/rear		1290mm(50.8 inches)/1290mm(50.8 inches)
	Curb Weight		858 kgs
Tyres	Front		145/70R12
	Rear		145/70R12
Brake System	Front		Disc
	Rear		Drum
Suspension system	Front		double wishbone independent suspension
	Rear		Disconnected after trailing arm type independent suspension
Other Parameter	Steering system		Left hand drive / Right hand drive
	Body Type		Steel body
	Available Colour		Red, Green, Orange, Blue, Yellow, Pink, White, camouflage
	Country of Origin		Chongqing, China
Loading Volume	CBU (completely built up)		12 units/ 40HQ container
	CKD (completely knocked down)		20 units/ 40HQ container
Unit Price	CBU	Carburetor Engine
		EFI Engine
