Help CenterChina Bigmt Electric Classic Style Mini Moke
Related Products
Specifications
1, Classic style design.2, Perfect performance of engine.
3, RHD(right handle drive) or LHD system is available
Dear Latent clients,
Hellooo.
Please allow me to introduce our company for the first time.
At present, except for the pure foreign trade business, we are also searching for partners all over the developing regions to establish simple auto assembly plants in the locality, as such countries in Africa, the Middle East and Central America.This is quite a feasible and profitable project
indeed, because we have already set up assembling lines in Syria, Ghana and Costa Rica. In order to accomplish our ultimate goals that to develop, occupy and hold all the strategic significant marketing highlands of the third world countries.We now need to enhance our business coverage by adding a few more real foothold to form a entirely marketing system.
If you requested, we will send you more imformation about our project.
Other Details about our mini moke
Engine
Item
Mini Moke
Engine Type
in-line 4-cylinder, 4-stroke, EFI gasoline engine
Max. Power
33.5 w/ 5000 rpm
Max. Torque
72/3000-3500 (N.m/ rpm)
Start
Electric Start
Cooled system
Water Cooled
Transmission Type
5+1
Wheelbase
2100 mm (78 inches)
Wheeltrack front/rear
1290mm(50.8 inches)/1290mm(50.8 inches)
Curb Weight
858 kgs
Tyres
Front
145/70R12
Rear
145/70R12
Brake System
Front
Disc
Rear
Drum
Other Parameter
Steering system
Left hand drive / Right hand drive
Body Type
Steel body
Available Colour
Red, Green, Orange, Blue, Yellow, Pink, White, camouflage
Country of Origin
Chongqing, China
Loading Volume
CBU (completely built up)
12 units/ 40HQ container
CKD (completely knocked down)
24 units/ 40HQ container
| PARAMETERS | DATA | ||
| DC system | AC system | ||
| wheel base | 2,020 mm (78 inches) | ||
| wheel tread | 1,290.00mm(50.8 inches) | ||
| MASS | net weight | 400 kg | 420 kg |
| rated passenger capacity | 3/4 person | ||
| WHEEL SIZE | front wheel size | 145/70R12 | |
| rear wheel size | 145/70R12 | ||
| stopping distance | ≤7.5m (30km/h) | ||
| continuable running distance | 100 km | ||
| rapidity Classs | 2 ; 4 | ||
| climbing capacity | 16.6° | ||
| ELECTRICAL EQUIPMENT | controlling unit | 72V,350A | 72V,300A |
| controlling fuse | 380V /10A | ||
| head light | 12V, 35W/35W | ||
| F/R brake light | 12V, 10W/5W | ||
| front light | 12V, 5W | ||
| turning light | 12V, 10W | ||
| reverse light | 12V, 10W | ||
| battery set | 72V,210A/h (6V/piece,12pieces) | ||
| motor power | 72V, 5kw | 72V, 6.3kw | |
| recharge voltage | 220AC | ||
