Help CenterSolder Smoke Absorber/Smoking Device Smoking Instrument XY201/Single Phase Active Carbon Fume Extractor
Related Products
-
Fume Extractor/Solder Smoke Absorber/Smoking Device Smoking Instrument XY201T/Single Phase Active Carbon Fume ExtractorNegotiableMOQ: 1 Set -
Smoke Absorber/Fume Extractor Soldering/Smoking Device Smoking Instrument XY202/High Efficient Laser MachineNegotiableMOQ: 1 Set
-
Fume Extractor/Solder Smoke Absorber XY201T/Portable Laser Soldering Fume Extractor/Smoke Absorber ManufacturersNegotiableMOQ: 1 Set
-
Smoke Absorber/Fume Extractor Soldering/Smoking Device Smoking Instrument XY202/high Vaccum Fume ExtractorNegotiableMOQ: 1 Set
-
Fume Extractor/Solder Smoke Absorber Manufacturers/Solder Smoking Device Smoking Instrument XY201TNegotiableMOQ: 1 Set
Features:
*Filter compact structure, easy installation;
* Incorporate brushless, maintenance free centrifugal motor, long use life, little noise;
* Triple filter design ensures to filter out harmful smoke and protect operators’ safe; The first filter, middle filter and main filter can be replaced independently;
* Inner filter cycle system that avoids inside cool/hot air to the outdoor;
* Multi work-station design, adjustable air flow, flexible and adjustable arm;
Filtration principle:
Toxic and hazardous gas / dust→the first filter→the second filter→activated carbon filter→high efficiency filter→clean air
|
Model |
XY201 |
XY202 |
|
Work-station (Arm No.) |
1 |
2 |
|
Pressure |
900Pa |
|
|
air flow |
200m3/hr |
320m3/hr |
|
System flow(including filter device) |
160m3/hr |
2*100m3/hr |
|
filter efficiency |
0.3μm 99.97% |
0.3μm 99.97% |
|
power consumption |
80W |
120W |
|
noise |
<55dB |
|
|
arm length |
Length:1.5m |
|
|
input voltage |
220V AC |
|
|
dimension |
410(L)×235(W)×365(H)mm |
475(L)×235(W)×510(H)mm |
weight |
About10kg |
About18kg |
