Specification:
|
Model |
XY201T |
XY202T |
|
Work-station (Arm No.) |
1 |
2 |
|
Pressure |
2000Pa |
|
|
air flow |
235m3/hr |
350m3/hr |
|
System flow(including filter device) |
170m3/hr |
2*170m3/hr |
|
filter efficiency |
0.3μm 99.97% |
0.3μm 99.97% |
|
power consumption |
80W |
120W |
|
noise |
<55dB |
|
|
arm length |
Length:1.5m |
|
|
input voltage |
220V AC |
|
|
dimension |
410(L)×245(W)×395(H)mm |
410(L)×245(W)×395(H)mm |
|
weight |
About15kg |
About16kg |
Features:
1.Integrated design of machine structure, high quality metal plate baking varnish technology, high intensity, good impact resistance
2.Smoke Absorber XY202T can be used upon connection, being installed easily and conveniently and operated easily.
3.Smoke Absorber XY202T is equipped with smart control panel, making operation simple; digital display makes running status mastered at real time.
4.Stepless speed regulating through touch-button makes air quantity adjusted at will.
5.Equipped remote-control unit realizes remote operation.
6.Sensitive and effect “Filter element blocking warning system” — automatically give acousto-optic warning if the filter element is blocked for 10 seconds, prompting users to change filter and avoiding unnecessary consumption.
7.smoke filtering system is lower than the use-cost of “Pipeline exhaust system” in use-cost, better in smoke-absorbing effect and higher value-preserving rate. It can avoid discharging indoor cold air ( or warm air), keep the cleanliness of indoor air, save energy and beautify the environment.
8. Smoke Absorber XY202T “High-Pressure Mass-Flow Centrifugal Fan” with two applied patents—— low noise, small vibration, stable running, long life-span, low electricity consumption, high efficiency (Zero maintenance and zero consumables of DC brushless motor spare parts).
9.Specially-designed alloy eddy current wind wheel is featured by fatigue-resistance, stable running, low noise, large air volume and high efficiency.
10.Multistage filtering design guarantees the thorough harmful matters filtering in smog. Preliminary-effect, medium effect and main filtering elements can be changed independently. Not only does this designing form lengthen the using-span of filters, but also lowers the using cost of filters.
11.Smoke-absorbing wind pipe with two patents has good stationarity. It can be used upon connection, changed in direction and positioned randomly. The length of pipeline can be controlled conveniently and fast. Other smoke-absorbing pipeline shall not be paved additionally.
12.Smoke-absorbing covers with two patents adopts high-quality silicon rubber can resist airflow to some extent, avoiding the effect of air to smoke-absorbing effect and resisting the 400°C high-temperature without damage.
