2015 New Design 72V 5KW AC System Motor Eec L7e Electric Car Quality Choice

2015 New Design 72V 5KW AC System Motor Eec L7e Electric Car Quality Choice thumbnail-1
2015 New Design 72V 5KW AC System Motor Eec L7e Electric Car Quality Choice photo-1
US$ 6,899 - 6,999 MOQ: 6 Units
Key Specifications
Get Latest Price
Type:
Sedan
Fuel:
Electric
Gear Box:
Semi-Automatic
Contact Supplier Request Quote Chat Now
Chongqing Big Science & Technology Development Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Sedan
Fuel Electric
Gear Box Semi-Automatic
Made In China
Steering Left
Drive RWD
Brand Name customized
Place of Origin China
Model Sedan
Year 2015
Month 2



2015 new design 72V 5KW AC system motor eec l7e electric car:

1.  5KW AC system motor;

2.  72V(9pcs 8V/pcs) Maintenance-Free Lead-Acid Battery;

3.  CVT transmission;

4.  Rear Engine Rear Drive (4x2 /2WD, RR)





2015 new design 72V 5KW AC system motor eec l7e electric car




Product Description

--- Main Technical datas of the "eec l7e electric car":



Technical Parameter of the Electric Four Wheel Car (with EEC)
Parameter Quadricycle Remarks
Body Structure Frameless Body, fully colsed metal structure, 5 doors 4 seats
Drive Type Rear Engine Rear Drive (4x2 /2WD, RR)
Basic Parameter Overall Dimension (L*W*H) mm 3090*1420*1480
Wheelbase 2170
Wheel Track (front) 1215
Wheel Track (rear) 1235
Front Overhang 464
Rear Overhang 451
Trunk Volume L 60
Passenger (capacity) person 4
Weight Curb Weight kg 820
Loading Capacity 300
Net Weight 480
Trafficability Approaching Angle (°) 30
Descent Angle 42
Steering Angle ≤30
Obstacle Height mm ≤120
Obstacle Width ≤120
Min Turning Radius 4440
Min Ground Clearance 130
Transmission CVT
Body Type & Parameter Power 5kw 72v AC (with EEC) Controller G8035 *range and speed will vary
depending on temperature,
terrain, driving style, road
conditions, or vehicle
payload
DC-DC DC72-84V
Motor 5KW 72V AC
Max Speed ≥40km/h, Economic Model
≥60km/h, Sport Model
Accelerating Ability 0-30km/m≤10s
Distance Per Charge ≥220km
Rated Power 5.0KW
Max Climbing Capacity ≥20%
Max Power 12.5KW
MAX TORQUE 76N.m
Battery Type Maintenance-Free Lead-Acid Battery
Brand Chil Wee
Capacity 8V 150AH     9PCS
Charge Time 6-8 hours
Charger V/A 72 / 25
Steering Rack & Pinion
Brake System Front / Rear Brake Mode Disc / Drum
Operation Mode Hydraulic Braking
Parking Brake Hand Mechanic, Force on Rear Tyre
Brake Fluid DOT4
Filling Volume 500ml
Suspension Front Suppension Single Axle Independent Suspension
Rear Suspension Solid Axle Dependent Suspension
Tyre Aluminium Tyre Meridian Vacuum Tyre
Shaft Ball Cage Type Drive Shaft
EEC certificate No.: e9*2002/24*0509*01





--- Pictures of the "eec l7e electric car":



1) External
