BST-28 computerized and continuous stitching machinery

Specifications

Copied Mammut quilting head,
High speed quilting head,
Continuous quilting,
Automatic feeding,
Automatic cutting



BST-28 Computerized and Continuous Single needle quilting machine



Uses:
Quilt matress, coverlet, bedcover, sponge, leather and so on.



Main Specifications:

Quilting width:	≤2400mm	Needle model:	130/21
Quilting length:	≤2600mm	Rotating speed of needle:	0-2500RPM
Quilting thickness:	≤80mm	Total power:	8.8Kw
Gross weight:	3500kg	Power:	3X 380V 50Hz
Stitch length:	2-8mm	Overall dimension:	8600mmX3740mmX1900mm



FEATURES:
1.Adopt advanced outsize lock stitch sewing, auto thread-breaking checking and quilting. Thepresser foot can be adjusted to different thickness.
2.Equipped with high-capacity computer that can deal with various kinds of complicated patterns. Can run by continuous or interval way according to fabric and processing requirement.
3.3600 jump quilting, pattern effect display, processing locus display, thread auto-cutting, needle auto-lifting, auto-stop when thread-breakage, etc.
4.Adopt Japan servo motors for controlling ensuring more precision.
5.Low noise, low vibration, stable performance.
6. Quilting pattern storage: about 200 patterns kept in the computer, also can read from USB, the pattern file is .dst.
7.Auto cloth feeding and pulling, automatic cutter according customer choice.
