Home > Packaging & Printing > Printing Machinery > Printing Machinery Parts > Xaar XL500/80 Printhead, Printing Head for Xaar Printer

Xaar XL500/80 Printhead, Printing Head for Xaar Printer

Name: Xaar XL500/80 Printhead, Printing Head for Xaar Printer
Brand: Chinasigns
SKU: 120918303
Availability: InStock

Xaar XL500/80 Printhead, Printing Head for Xaar Printer thumbnail-1

Xaar XL500/80 Printhead, Printing Head for Xaar Printer photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Beijing, China

Brand Name:

Chinasigns

Model Number:

PRH-XAAR-007

Contact Supplier Request Quote Chat Now

Beijing Chinasigns Information Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/Shanghai/Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Beijing, China

Brand Name Chinasigns

Model Number PRH-XAAR-007

Type Other, Printing head for Xaar Printer

Use Other, Xaar XL500/80 Printhead

Printing Type Inkjet Printer

	Xaar 500 40	Xaar 500 80
Active nozzles	500	500
Print swathe width	70.5 mm	70.5 mm
Nozzle pitch	141 μm	141 μm
Drop velocity*	6 m/s	6 m/s
Nozzle density	180 npi	180 npi
Printhead weight (dry)	290 g	290 g
Fluid type	Approved range of inks	Approved range of inks
Drop volume*	40 pL	80 pL
Typical firing frequency*	8.0 kHz	4.0 - 7.2 kHz
Dimensions (WxDxH)	95x41x110 mm	95x41x110 mm

Xaar 500/80 printhead
To be used with: MYJET LA3208XR,MYJET LA3204XR, MYJET LB3204XR, MYJET LB3208XR, MYJET WD3212XR, MYJET WD3216XR, LIYU PE3204-XR382, LIYU PE3208-XR382, SMART PROTON 8H, Wit-color Ultra2000 H4/H6, WIT-COLOR ULTRA2000 H8, WIT-COLOR ULTRA2000 H12, WIT-COLOR ULTRA2000 H16, SMART 600 8H, SMART3000 4H, SMART3000 6H, SMART3000 12H, SMART2000 S12, SMART2000 S16, SID UV 165P, Flora 3204 E, Flora HJ3200 Solvent
Remarks: Original

Description:
The Xaar 500 offers a versatile binary inkjet solution for a number of applications and is particularly suited to coding secondary packaging and printing outdoor signs. The Xaar 500 printhead is available in two drop volume variants (40 pL and 80 pL). It can be used in standard or skyscraper (vertical) printing modes depending on the application.

High performance
• Up to 7.2 kHz firing frequencies
• UV, solvent-based and oil-based ink capable
• 180 dpi (native) printhead resolution.

Highly versatile
• The 40 pL model meets the demands of the high quality UV wide-format and solvent graphic markets
• The 80 pL model leads the way in the solvent grand-format coding and marking markets.

Application:
The Xaar 500 is a competitive, high quality and fast output printhead. The wide print swathe, ink compatibility and reliability make the Xaar 500 the printhead of choice for many applications including:
• Coding & marking;
• Wide-format graphics;
• Grand-format graphics;
• Flatbed graphics;
• Indoor signage;
• Outdoor graphics;
• Point-of-sale material.

Attention:
1. The printhead is required to be installed by professional persons.
2. Due to the nature of printer parts and the many factors that go into installing them, we do not accept returns or give refunds on electronic or service parts. Once the package is delivered, it is the customer's responsibility to check the package for damage. If there is any visible damage on the package, please refuse the shipment and call us at +86(10) 63705868 ext 607 or send to
3. Please seriously pay attention on information of printhead model while purchasing from us. Once received your item, please inspect if the printhead matches up with the model you required.If you have any problems, it is very important that contact us as soon as possible before installing it onto machine. Please be aware that we don't accept any return and refund once the printhead is installed on the machine.
