WAW computer control electro-hydraulic servo universal testing machine
Model: WAW-100
we supply kinds of specifications of this product as WAW-100,300,600,1000,2000 etc.
Model: WAW-100 |
Maximum test force:100KN |
Host structure type: Two column |
Power Indication accuracy: Better than ±0.5 % or ±1% |
Load resolution (KN): 1 / 500000 of full range |
Effective force measurement range (KN): Maximum test force of 2% to 100% |
deformation accuracy: Better than ±0.5 % or ±1% |
Deformation Resolution (μm): 2 |
Displacement indication Accuracy: Better than ± 1% |
Stress control speed (Mpa / s):1~45 |
Strain control speed (mm / s):0.001~0.5 |
Displacement control speed (mm / s):0.02~3 |
Stretching space (mm):600 |
Compression space (mm):550 |
effective width(mm):460 |
Cylinder stroke (mm):200 |
hydro-cylinder underneath type (Double space): 720*580*1770 |
Round sample size (mm): Φ5~Φ20 |
Flat sample size (thickness × width mm): 0~15*75 |
Function and characteristics:
1, Automatic control, measurement, data acquisition and processing, drawing and printing test curve (which parts can be zoomed in or out ) and test reports;
2, Monitoring system being calibrated and turned to zero automatically;
3, Testing force, deformation and displacement are controlled by speed,and the controlling error is less than ± 1% of settings;
4, Stepless speed regulation, control speed and control way can be converted randomly in the testing and also can be keeped;
5, Data storage and amplification of curve. In testing ,it can be arbitrary show different test curve;
6,In programme process, it can be converted to manual control ,adjust manually and control speed at any moment.
7, Automatic protection if testing force overloading; the scope of protection can be arbitrary setted,such as can be setted to 5% or 10% of the max testing force;
8, It can be conducted on network between testing labs and convenient for management.
