Home > Instruments & Meters > Test Instrument > Test Machine > LDW Electronic Tensile Testing Machine Door Type

LDW Electronic Tensile Testing Machine Door Type

Name: LDW Electronic Tensile Testing Machine Door Type
Brand: East
SKU: 120914167
Availability: InStock

LDW Electronic Tensile Testing Machine Door Type thumbnail-1

LDW Electronic Tensile Testing Machine Door Type photo-1

US$ 2,030 - 9,900 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

East

Model Number:

LDW

Contact Supplier Request Quote Chat Now

Jinan East Testing Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name East

Model Number LDW

Power Electronic

Usage Tensile Testing Machine

Digital Display Electronic Tensile Testing Machine

1.LDW digital display electronic tensile testing machine carry out the measurement under the control of single chip microcomputer. It features mechanical loading, synchronous belt driving, electronic measurement, digital display, continuously adjustable test speed, and auto stop after snap. The testing force and the displacement are digitally showed spontaneously. It also functions of test force holding and displacement peak value holding. Accessories can be attached to carry out tests of compression and bending. Digital display electronic tensile testing machine is widely used in the mechanical perform tests of components, parts and materials including rubber, plastic, wire, cable, textile, waterproof materials, non- woven fabric, metal paper, metal sheet, metal plate, metal bar, etc.

2.The digital display electronic tensile testing machine is equipped with protection systems including position limit, automatic shut off on overload, automatic power off on over current or current leakage. Its main machine is driven by imported servo motor and servo driver. The synchronous belt and the ball screw mechanism contribute to the smooth operation, little noise and little oil contamination of the driving system. Each testing machine is accompanied with a tensile fixture fit for different testing material. The fixture can be altered as demanding and other accessories are also available.

3.Specifications

Model	LDW digital display electronic tensile testing machine
Structure	Single-arm-type	Desktop type	Landing door type		Double space landing door type
Testing force(KN)	0.1-5	0.1-20	5,10,20,50	100	200	300
Load testing range	2%-100%
Load testing accuracy	±1%
Effective testing width(mm)	—	350	410	450	550	_
Stretching space(mm)	650	650	650		700
Speed range	0.1-500mm/min		0.1-500mm/min	0.1-500mm/min	0.2-300 mm/min
Speed control precision	±1%
displacement	resolution 0,1mm
Overall dimensions	400×300×1200mm	620×370×1250 mm	700×410×1680 mm	760×480×1780 mm	1000×570×2200 mm
Power(kw)	0.5	0.8	1.2	1.5	2	3
Voltage	220v,according to national standard voltage configuration
Weight	80kg	120 kg	300 kg	600 kg	1200 kg	1300 kg
Standar configuration	1 main machine, 1 liquid crystal display watch, 1 stretching clamp, 1 compressing disc. Other tools can be customized according to customer requirement.

4.Digital display electronic tensile testing machine is suitable for tests with lower requirement. This testing machine can only show the maximum testing force. The tensile strength and bending strength shall be obtained by manual calculation. It does not have the function of automatic computer processing or testing curve display, so it can neither measure yield strength nor print nor print A4-breath testing report.

Related Names

Digital Display Universal Testing Machine/ Test equipment/ Tensile Tester/ Tensile Testing Machine
