us type G210 electric galvanized shackle
| MATERIAL: | High tensile steel | ||
| CONSTRUCTION: | Quenched and Tempered | ||
| STANDARD: | U.S. Fed.Spec.RR-C-271 | ||
| SAFETY FACTOR: | 6*WLL | ||
| working load limit | diameter bow(mm) | width inside(mm) | diameter pin(mm) |
WLL1/3T |
5 | 9.5 | 6 |
| WLL1/2T | 6 | 12 | 8 |
| WLL3/4T | 8 | 13.5 | 10 |
| WLL1T | 10 | 17 | 11 |
| WLL1 1/2T | 11 | 19 | 13 |
| WLL2T | 13 | 20 | 16 |
| WLL3 1/4T | 16 | 27 | 19 |
| WLL4 3/4T | 19 | 32 | 22 |
| WLL6 1/2T | 22 | 36 | 25 |
| WLL8 1/2T | 25 | 43 | 28 |
| WLL9 1/2T | 28 | 46 | 32 |
| WLL12T | 32 | 51 | 35 |
| WLL13 1/2T | 35 | 57 | 38 |
| WLL17T | 38 | 60 | 42 |
| WLL25T | 45 | 73 | 50 |
| WLL35T | 50 | 84 | 57 |
| WLL55T | 64 | 107 | 68 |
| WLL85T | 76 | 127 | 80 |
Widely used in electric power, metallurgy, petroleum, machinery, railway, chemical industry, ports, mining, oil & gas, fishing, offshore, construction and other industries.
We are a rigging series manufacturer in qingdao, shandong of China.
Our factory is built on 1995s. And we already have twenty years experience on rigging hardware.
In order to meet the customer's need we have built rich stock about shackle turnbuckles in our factory.
a.) forged press machine (4 lines :300t;400t;630t;1000t)
b.) heat treat machine(facality:net type furnace/box type furnace/pit furnace)
c.) inpect equipment:100 tonnes universal test machine(has passed qingdao quality superivise bereau inspect)
d.) rockwell hardness test machine (has passed qingdao quality superivise bereau inspect)
We inspected product one by one before shipment and finished products are not allowed on the ground.
Packing
a.) forged press machine (4 lines :300t;400t;630t;1000t)
b.) heat treat machine(facality:net type furnace/box type furnace/pit furnace)
c.) inpect equipment:100 tonnes universal test machine(has passed qingdao quality superivise bereau inspect)
d.) rockwell hardness test machine (has passed qingdao quality superivise bereau inspect)
We always take part in rigging hardware show on home and abroad.
Our manager is talking with our customers about our rigging hardware products in the Germany Fair show.
We have obtained ISO9001-2008 Quality System Certificate early in this industrial. Our products can pass the test for some famous testing organizations,such as SGS, BV, etc..
