Specifications
1.Size: 2mm-13mm link chain2.Finish: hot dip galvanized, zinc plated
Product Description
DIN 5685 A/C Short/Long Link Chain
1.Size: 2mm-13mm link chain
2.Finish: hot dip galvanized, zinc plated
| SIZE | INSIDE LENGTH | OUTSIDE WIDTH | WEIGHT PER 100M | WORKING LOAD | BREAKING LOAD | GRADE |
| MM | MM | MM | KG | N | N | |
| 2 | 12 | 8 | 7 | 500 | 1250 | A |
| 22 | 6 | C | ||||
| 2.5 | 14 | 10 | 11 | 750 | 2000 | A |
| 24 | 10 | C | ||||
| 3 | 16 | 12 | 16.5 | 1120 | 2800 | A |
| 26 | 15 | C | ||||
| 4 | 19 | 16 | 30 | 2000 | 5000 | A |
| 32 | 27 | C | ||||
| 5 | 21 | 20 | 50 | 3150 | 7750 | A |
| 35 | 43 | C | ||||
| 6 | 24 | 24 | 73 | 4500 | 11500 | A |
| 42 | 63 | C | ||||
| 7 | 28 | 28 | 100 | 6000 | 15000 | A |
| 49 | 86 | C | ||||
| 8 | 32 | 32 | 130 | 8000 | 20000 | A |
| 52 | 110 | C | ||||
| 9 | 36 | 36 | 165 | 10000 | 25000 | A |
| 59 | 141 | C | ||||
| 10 | 40 | 40 | 205 | 12500 | 31000 | A |
| 65 | 175 | C | ||||
| 11 | 44 | 44 | 250 | 15000 | 38000 | A |
| 72 | 211 | C | ||||
| 12 | 48 | 48 | 290 | 18000 | 45000 | A |
| 78 | 255 | C | ||||
| 13 | 52 | 52 | 345 | 21200 | 53000 | A |
| 82 | 295 | C |
Application
Widely used in electric power, metallurgy, petroleum, machinery, railway, chemical industry, ports, mining, oil & gas, fishing, offshore, construction and other industries.
About us
1. We are an experienced manufacturer.
2. Our chains are made of selected steel material. We provide the chains with the best quality and the most reasonable price.
3. We can provide the chains:
1) Grade: G80, G70, G60, G43, G30 welded link chain
2) Surface treatment: Self color, black oxide, electro galvanized, hot dip galvanized,
black painted etc.
3) Material: 20Mn2, 25Mnv, 23MnNiMoCr54, Q235
4) Standard: National Standard (GB/T20947-2007), International Standard (ISO3077-2001), American Standard (NACM, ASTM), European Standard (EN818), AS/NZS Standard
