60w 12v 5a Low Voltage Power Supply Constant Current Power

60w 12v 5a Low Voltage Power Supply Constant Current Power thumbnail-1
60w 12v 5a Low Voltage Power Supply Constant Current Power photo-1
Negotiable MOQ: 10 Cases (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ZH
Model Number:
ZHS-60-12
Contact Supplier Request Quote Chat Now
Shenzhenshi Zhenhuan Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shekou Port in Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ZH
Model Number ZHS-60-12
Output Power Other, 60W
Output Type Single
Input Voltage Other, 85-132VAC / 180-264VAC
Output Voltage 12V
Output Frequency 47Hz~63Hz
Output Current 5A

Specifications

low voltage power supply
1. Safety certification
2. 10 years of production and R & D experience

60w 12v 5a low voltage power supply constant current power

If this item can't meet your requirements, please do let me know, because there are other kinds of Switching Power Supply in our company. The power from 5W to 500W

60w 12v 5a low voltage power supply constant current power60w 12v 5a low voltage power supply constant current power60w 12v 5a low voltage power supply constant current power

Power supply Product Description

Input specification

Input voltage

AC 100V-240V


Input frequency

47-63Hz

Output specification

Output voltage can be adjusted

±1%


Start-up time

<1S(input230V,Io=100%)


keep time

>20mS (input230V,Io=100%)


Voltage regulation

(Full load) <0.5%

Protection function

Overload protection

105% - 150% rated power, automatic recovery


Over-voltage protection

105% - 150% of the rated voltage

Insulation intensity

Input---output

1500VAC/1min


Input---ground

1500VAC/1min


Input---ground

500VAC/1min

Environmental

working temperature

- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)


Storage temperature

- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)


height above sea level

<2000M

Cooling method

Cooling method

Through the fan make temperature decrease

Product Type Table

60w 12v 5a low voltage power supply constant current power

Production Process

1.Purchasing the materials

60w 12v 5a low voltage power supply constant current power

2.Retouching-Testing: to make each products quality best.

60w 12v 5a low voltage power supply constant current power

3.Assemblin

60w 12v 5a low voltage power supply constant current power

4.Aging:To test the products working life and make each product can be used as possible

as long time.

60w 12v 5a low voltage power supply constant current power

5. Product outbound and package

60w 12v 5a low voltage power supply constant current power



60w 12v 5a low voltage power supply constant current power

6.Certificates

Amost all of our products get UL/ CE/ GS/ KC/ SAA/ 3C/ PSE/ CB/ ROHS etc

certificates, and if you have Special requirements of certificates,we can help to apply for you

60w 12v 5a low voltage power supply constant current power60w 12v 5a low voltage power supply constant current power

Our working environment

Shenzhen Zhen Huan Electronic Co., Ltd.  is an excellent power solution provider, with more than

10 years' experience in R & D and production of power supplies. We are committed to provide the

highest quality products and services with the best prices and the most punctual delivery time.



Our products are 100% through high temperature ageing, which accords with UL, CE, GS, FC, SAA

 and many other authoritative organization security authentication standard. In order to ensure timely

delivery, we always keep standard product inventory. If you can't find the right type from our product

display or you can't find the right product in the market, please contact us, we will develop satisfactory customized products for you.



We always adhere to the corporate value of "excellent quality and high efficient service" to provide you

the best service.
