TM-UV-F2 offset UV dryer offset printing dryer
| Type | Power | UV Lamp |
Insertwidth (mm) |
Distance from belt to ground |
Weight (Kg) |
Electric control box size | Body size |
offset print speed (pcs/h) |
|---|---|---|---|---|---|---|---|---|
| TM-UV-F1 | 380v 3phase | 2pcs*5.6kw | 850 | 400mm | 500 | 60*97*99cm | 270*110*135cm | 2000 |
| TM-UV-F2 | 380v 3phase | 2pcs*8kw | 850 | 400mm | 500 | 60*97*99cm | 270*110*135cm | 3000 |
| TM-UV-F3 | 380v 3phase | 4pcs*8kw | 1100 | 820mm | 1000 | no | 400*135*145cm | 6500 |
| TM-UV-F4 | 380v 3phase | 3pcs*9.6kw | 1100 | 820mm | 1200 | 60*97*99cm | 400*135*145cm | 6500 |
Features:
(1) With teflon or stainless street net, trasmit speed steady and can be adjusted (0-70m).
(2) With two UV lighting tubes, can turn on the light according to the need.
(3) Wink-dry make the surface of the stocks high hardness and rub resistance.
(4) Tunneling-based make the whole machine light barrier good and without harm.
(5) Equipped with powerful nether induced draught system and big intake airway, can absorb the stock on the mesh belt hard.
(6) Can be used with production line and other equipment easily.
Special UV machine of printing machine: Exact design, complete function, stable performance, each switch is obvious and easy to distinguish, simple and convenient operation, optimal high quality printing machine connecting UV solidifying machine and best partner of Heidelberg, Man Roland and Komori and so on.
Quality, special design, and advantages of main parts:
(1)Adopt imported UV light tube, and have long useful time, and more stable wavelength.
(2)Adopting glisten film made in Germany and installing specially designed focused lampshade can promote UV energy effectively, and make the solidifying ability of the machine stronger.
(3)Exclusive design of ultralow temperature of irradiated area makes printing heat sensitive paper, film, and 0.05mm thin film not become deformed, and reprint exact.
(4)The machine adopts specially designed heat removal system, drops off UV heat, and also does not lower UV energy, makes materials stable, does not float, stop, trap in the light chest
(5)Light source is divided into bright light, middle light, and dim light, unattached switch allocating energy-saving leakage transformator produced by the factory make the energy of UV light exert to the highest-level, meanwhile save electric power changes.
(6)The machine is equipped with transformer and overtemperature protection device of lighting tube.
(7)Divided design (fuselage is separated from mainframe) is easy to operate, and can be pushed.
(8)The machine prints with printing machine at the same time: discharge velocity of rapid solidifying is 70m per minute(mph 6000 pieces of paper).
(9)The machine has many types, and can be made to order according to the requirements of customers, the solidifying speed is 5-70m/min and can be adjusted.
